• Type：High-speed Stranding Machine
• Motor：Siemens
• Inverter：Siemens
• Single Wire Size：0.08-0.64
• Production Speed：2500 R,Min
• Twisting Section：0.05-6 mm Square mm
• Twisting Distance：4.2-130mm
• Power：5-10HP
• Gross Weight：Max 250-400kg
• Net Weight：2000-4000kg
• Finished Wire Range：16-30AWG
• Transport Package：Wooden Packing or PE Film Sample Packing
• Specification：1900*750*950mm
• Trademark：Tianxin
• Origin：Dongguan, China
• HS Code：84772090
• Production Capacity：20 Set,Month

TX-650TwistingApply to over 7thread silver plate wire,tin plated wire,enamelled wire,
naked copper wire,CCS,CCA etc super fine conductor and cored
wire twisting.Finished range18-30AWG16-26AWGTwisting section(mm2)0.05-2.500.80-6.00Diameter of single wire(mm)Φ0.08-0.41Φ0.12-0.64Twisting distance(mm)4.22-39.64(30 kinds of twisting diameter)4.20-130.00Gross weight(kg)Max 250Max 400Max high axis rotation speed 2200rpm(4400t/min)/3000rpm(6000t/min)1800rpm(3600t/min)Twisting directionTo left or rightFlat cablePolish rod traverse unit,pitch & throw adjustableTake-up tension trackTension adjustable,pulled wire no deformationAuto-stop machine1.automatic brake in case of broken wire,in the body, the body outside
Automatic meter, the meter automatically brakeMachine using bearing Main bearing made in Sweden,others in JapanPower(HP)5-7.5HP controlled inverter10HP controlled inverterNoise level(dB)Approx 75Approx 80Machine dimension(mm)(L)2690×(W)1060×(H)1230(L)2850×(W)1500×(H)1600Net weight(kg)Approx 2000Approx 4000
Why us?

We are the cable equipment manufacturer
Professional engineer, long term to research and development for to cable equipment .
High frequency capacity manufacturer machine is provide .Guarantee the machine all weather running.
Our machine use the international qualified brand, like Siemens ,Omron,NSK,LG etc.
Install and training service. Guarantee overseas install and cable manufacture training experience.
Technical support and spare parts service.

We DO not only provide the high quality machinery products, but also design the full set of equipment for you.

PAYMENT:
1. T/T or L/C (advise)
2. Wooden packing or PE film sample packing ( Customer requirements )
3. We 'll do house inspection for every machine before loading it, and also inspected by buyer in person.

HOW TO REACH OUR FACTORY:
1.Only 35 minutes from Guangzhou city to Dongguan city by high speed train.
2.Just 40 minutes from Shenzhen city to Dongguan city by high speed train.
3.Total 1.5 hours by car from Guangzhou airport to our factory .
4.Only 0.5 hour by car from Shenzhen airport to our factory.
