CNC Magnetic Electric Micro Transformer Coil Winding Machine
Tianjin Grewin Technology Co., Ltd.- Voltage：220V
- Warranty：1 Year
- After-sales Service：Operation Video Tutorial
- Wire Diameter：0.05-1.1
- Max.Final Coil.O.D：8-60
- Min.Final Coil.I.D：3
Base Info
- Model NO.：GW-9020B4
- Spread Motor：Stepping Motor
- Controller Storage Capacity Programs：999 Sets
- Max.Winding Speed：1500rpm
- Winding Motor：1,2HP DC Motor
- Supply Voltage：AC 220V(50Hz)
- Mechanical Dimensions：600*620*550
- Weight：70kg
- Automatic：Automatic
- Certification：RoHS, CE, ISO
- Key Word：Voice Coil Winding Machine
- After Warranty Service：Online Support
- Key Words：Digital Winding Machine
- Transport Package：Export Standard Carton or Customize Strong Pallet
- Specification：CE
- Trademark：Grewin
- Origin：China
- HS Code：85043190
- Production Capacity：100PCS
Description
According to the machine head and shuttle size
FEATURES:
Digital Stepping Motor Coil Winding Machine has Hi-tech shuttle for highest efficiency.
Digital Stepping Motor Coil Winding Machine has separate speed controls for loading and winding.
Digital Stepping Motor Coil Winding Machine has accurately count length of loading by limited-switch.
Accurately count turns of winding by photo-electricity sensor
Programmable winding direction, winding returns range (Turns or Angle) and segment winding angle
Accurately wire spacing by programmable controller
Memory capacity accommodates 999 sequences of parameters with off-power memory retention for more than one year.
Automatic wire clamp and cut system, layer winding, material unloading and cleaning of the tool during each cycle.
Optional release agent dispensing to aid removal of the coil from the tooling.
Fine programmable pitch control enabling precise layer winding.
ADVANTAGES:
One year guarantee for whole machine
We can design and develop special machine based on your request
We can train customer how to operate and repair equipment
We supply full and quickly services when you use our products.
Corrosion resistant,High tensile strength,Easy to use
Optimum performance oriented
Why choose GREWIN INDUSTRIAL GROUP CO.,LTD:Following are our strong advantages:
1.We provide you the friendly English User manual or operating videos for free.
2.24 hours technical support by email or calling.
3.Warranty: 1 year free, 2-3 years cost price and free technical support always.
4.Free training to make sure you master the operating of our products.
5. OEM/ODM accept . But the MOQ of OEM/ODM is 100 sets.
Service tenet
Provide you the best service with "fast + satisfactory + safe".
Warranty period:
12 months long after the user received the product.
Warranty items:
Only for abnormal breakdown caused by the machine design or manufacture defect,free repair and accessory will be provided.
Technology service ability:
All service engineers with many years experience are gotten special technology training, who can deal with various breakdown problem.
Guide the user to use accurately and how to maintain the product.
Provide free consultation about production process technology of electronic products.
Service after sell:
In order to guarantee the machine used normally, we'd have training on how to operate, use and maintain our product by English manual, video, guiding on line.
Use instruction:
Apply for the right complete size of product, otherwise, the wrong dimensions will affect the use effect.
Do ensure using the product accord to the use instruction completely.Do not exceed the scope of application of the products.
Maintain the product after use,Damp proof, rust proof, leak proof, explosion-proof, regular maintenance and inspection should be taken care. All done help to extend the use period. Product packing:Wooden case package: For larger scale goods as machine equipment etc, we have special skilled carpenter, who would make the proper wooden case with exact thickness,density,length. The up arrow ↑marked on the outer wooden case. Buffer material would be put in the wooden case to prevent crack and shock. We will inform you the delivery note. You just need to wait for phone call, then pick up the goods at the nearest logistic station .(Please let me know in advance if you want get the goods at home.) Packaging: Packaging material: Carton/Wooden case with foam inside.
FAQ:1) This is the first time I use this kind of machine, is it easy to operate?
There is english manual or guide video that show you how to use machine.
If you still have any question, please contact us by e-mail / skype/ phone /trademanager online service.
2) If machine have any problem after I receive it, how can I do ?
Free parts send to you in machine warranty period.
If the part is less than 0.5KG, we pay the postage.
If it exceeds 0.5KG, you need to pay the postage.
3) MOQ ?
1 set machine, mixed order is also welcomed.
4) How can I buy this machine from you? ( Very easy and flexible !)
A. Consult us about this product on line or by e-mail.
B. Negotiate and confirm the final price , shipping , payment methods and other terms.
C. Send you the proforma invoice and confirm your order.
D. Make the payment according to the method put on proforma invoice.
E. We prepare for your order in terms of the proforma invoice after confirming your full payment.
And 100% quality check before shipping.
F.Send your order by air or by sea
