Programmable Vacuum Ovens for Reflow Soldering in Controllable Atmosphere
Termway (Beijing) Precision Technology Co., Ltd.- After-sales Service：Engineer Go Oversea for Training
- Condition：New
- Certification：ISO, CE
- Warranty：12 Months
- Automatic Grade：Semiautomatic
- Installation：Vertical
Base Info
- Model NO.：RS330
- Soldering Area：330*330mm
- Chamber Height：100mm
- Temperature Range：Room--450 C
- Voltage：380V 50A
- Max. Heating Rate：120c,Min
- Max Cooling Rate：180c,Min
- Cooling Way：Air-Cooled , Water-Cooled (Shell, Heating Plate)
- Transport Package：Polywood Case and Foam
- Specification：1200*1100*1400mm
- Trademark：TORCH
- Origin：Beijing, China
- HS Code：8514101000
- Production Capacity：100 Set,Year
Description
Model
RS330
Soldering Size
330*330mm
Furnace height
100mm(other Hights is optional)
Temperature Range
Up to 450ºC
Connector
Serial 485 network / USB
Control Mode
Software control (temperature, pressure, etc.)
Temperature curve
can store several curves Temperature of 40 segments
Voltage
380V
Rated Power
9KW
Actual Power
6KW(without vacuum pump)
Dimension
600*600*1300mm
Wight
250KG
The maximum heating rate
120ºC/min
The maximum cooling rate
Only water-cooled 60ºC/min, Air-cooled + water-cooled 120ºC/min
Cooling Way
Air-cooled / water-cooled (shell, heating plate)
Vacuum furnace Standard spare part :
