• Model NO.：HH-70MM
• Model Number：Hh-50+70+90mm
• Power(W)：50kw
• Weight：7000kgs
• Certificate：ISO,Ce
• After-Sales Service Provided：Engineers Available to Service Machinery Overseas
• Extrusion Capacity：390kg , Hour
• Screw Speed：120 Rpm
• Available Material：PVC, PE, XLPE, Lshz, TPE
• Transport Package：Wood Package
• Specification：CE ISO SGS
• Trademark：HOOHA
• Origin：Dongguan
• HS Code：8479400000
• Production Capacity：5 Sets,Month

HH-50MM Extrusion MachineNO.Condctorconductor sectionMax.WireInsulation materialMax.Speed1Solid0.5-10mm²10mmPVC,PE,XLPE,HFFR,LSHZ460M/MIN2stranded1.0-16mm²3Bunched0.5-25mm²
HOOHA Extrusion MachineNO.Pay offTension controllerMain estrusionCooling troughTractionTake up1630MM500KG50+35MMSingle layer  Double layer600KG800MM2800MM60+35MM1000MM31000MM70+35MM1250MM41250MM80+35MM1600MM   90+35MM
HOOHA Extrusion MachineNO.Model50+35MM60+35MM70+35MM80+40MM90+50MM1Pay off typeinitiatire typeinitiatire typeNo-axis magneticNo-axis magneticNo-axis magnetic2Screw L/D    3Out put110KG170KG210KG270KG390KG4Main motor15HP30HP30HP40HP50HP5Wire diameter1-4MM1.5-8MM2-10MM3-20MM4-45MM6Temperature control7 zones8 zones8 zones9 zones9 zones7Cooling deviceFolds W type/U typeFolds W type/U typeSingle layer/doubleSingle layer/doubleSingle layer/double8Capstan motor3HP4HP5HP7.5HP7.5HP9Take upDouble axisDouble axisNo-axis magneticNo-axis doubleNo-axis doublec



Consist of  Components:

1. Double shaft type Pay off stand
2. Dancer 3. Main extruder
4. Automated loader & dryer
5. Crosshead
6. Double layer Moving trough
7. Main cooling trough
8. Water wiper
9. Digital Diameter controller
10. Mark printer
11. Accumulator
12. Capstan
13. 15KV Spark tester
14. Meter counter
15. Dual shaft type Take up
16. Master control Control box
