Copper Electrical Wire Stranding Twisting Winding Plastic Making Extrusion Machine

Kunshan Fuchuan Electrical and Mechanical Co., Ltd.
  • Driven Type：Electric
  • Condition：New
  • Certification：ISO, CE
  • Warranty：12 Months
  • Automatic Grade：Automatic
  • Mould Life：300,000-1,000,000 Shots

Base Info

  • Model NO.：FC-250B
  • Single Wire Dia：0.03-0.18mm
  • Pitch：0.8-10.8
  • Take up Bobbin：Diameter 250mm
  • Main Motor Power：3.7kw
  • Inverter Power：3.7kw
  • Operation Mode：Touch Screen Operation
  • Max Rotating Speed：4000rpm
  • Transport Package：Standard Packing
  • Specification：ISO9001
  • Trademark：Fuchuan
  • Origin：Jiangsu Kunshan
  • HS Code：8479811000
  • Production Capacity：50sets,Month

Description

Equipment modelsFC-250BTwisting usageIt is applied to the twisting of aerospace, medical equipment, cellphone and ultra conductor(above seven pcs of bare copper wires, tinned wires, silver jacketed wires and enameled wires),double twisting for core wires.Single wire dia(mm)φ0.03-0.18Stranding section area (mm²)0.0049-0.3Pitch(mm)0.8-10.8(24zones)Direction of layOptional for right or leftOuter dia*bore*outer widthφ300*φ30*185Max rotating speed4000(8000twist)Main motor power3.7KWInverter power3.7KWTension control methodTouch screen+PLC+magnetic powder clutch,it may ensure the constant tension from empty bobbin to full bobbinMagnetic powder clutch0.3kgfProtectionMachine will automatically brake when wire inside and outside is broken,the machine will automatically stop when the preset length is arrived.Brake modeElectromagnetic brakeTraversing methodRolling ring drive units,winding pitch and breadth are adjustableOperation modeTouch screen operationDimension(mm)2300L*1100W*1330HCopper Electrical Wire Stranding Twisting Winding Plastic Making Extrusion Machine
