Automatic 4 Head SMT Pick and Place Machine (NeoDen4) with Auto Rails 48 Feeders for PCB Assembly PCB Board

Zhejiang NeoDen Technology Co., Ltd.
  • After-sales Service：2 Years Warranty
  • Condition：New
  • Speed：High Speed
  • Precision：High Precision
  • Warranty：24 Months
  • Automatic Grade：Automatic

Base Info

  • Model NO.：Neoden 4
  • Type：High-speed Chip Mounter
  • Pick Nozzle Qty：4
  • Tape Reel Feeder Qty：48
  • Vibrating Feeder Qty：5
  • Tray IC Capacity：5
  • Component Size with Vision：0201~Tqfp 240
  • Placement Speed：5000cph,H with Vision
  • Components′ Height：5mm
  • Positioning Accuracy：+,-0.02mm
  • PCB Area：310X1500mm with Internal Rails
  • Placement Area：140X1500mm with 1 Waffle Tray
  • Transport Package：Fumigation-Free Wooden Box
  • Specification：CE
  • Trademark：Neoden
  • Origin：Zhejiang
  • HS Code：84798962
  • Production Capacity：200sets,M

Description

Overview Product Description

Model No.: Neoden 4

Video show: http://pickandplace-neoden.en.made-in-china.com

Whole set: machine with rails+ 8mm feedersx5pcs+ 12mm feedersx 4pcs+ 16mm feedersx 2pcs+ worktable +Dell computor monitor

As showed above, this is just an example for a completed machine configuration, more choice for customers,
1. could  choose machine without rails.
2. could choose feeder size : 8mm, 12mm, 16mm,  could be different sizes and qty combination.
3. worktable and computor moditor could choose or not


Features:
1. with vision system high speed industry CCD camera brings high accuracy
2. online dual rails help automatic feeding board continously during mounting
3. speed with vision: 5000cph
4. support overlong LED strip 1.2m
5. leading mark point relocated technology in SMT line
6. 4 mounting heads, rotation 360 degree
7. support components 0201,BGA, SOT-23, QFN etc. which need high precision
8. on base windows
 Product Parameters



Neoden 4without Internal Railswith Internal RailsHead with Vision enabled QTY:4Mounting Speed:With vision: 5000/Without vision: 10000Mounting AreaWithout waffle Tray:310*400MMWithout waffle Tray:310*1500MMWith 1 waffle Tray:140*400MMWith 1 waffle Tray:140*1500MMSuitable ComponentsSmallest Component  size:0201 / Largest Component size:TQFP240Automatic FeedingNoneYesFeeder capacityTape Reel Feeders: 48(all 8 mm)Vibrations Feeders: 5IC tray capacity:5Component Max Height: 5MMResolutionX/Y axis:0.01MM     Z axis:0.1MMRotation:+/-180°(360°)Vacuum Pressure :0.9kpPower Supply:110V/220VPower:180WVision CameraCCD High AccuracyVision Qty: Dual VisionRecognition Capability: Max 30*30mmPacking size: 94*74*60CMExternal Dimensions Machine:87*68*48CM  Weight N.W:60KGS, G.W:80Kgs N.W:65KGS, G.W:85Kgs
Accessories:
1) Pick and Place Machine NeoDen4: 1
2) Nozzle: Totally 6
3) 8G Flash Drive: 1
4) Power Cord(5M): 1
5) Video training course: 1
6) Double Sided Adhesive Tape: 2
7)Allen wrench Set:5
8)Tool Box:1
9)Reel holder stand:1
10)Vibration Feeder:1
11)Rail Parts:4
12)User Manual:1

 Our Advantages

After Sales Service

FAQ

Q1: Do you provide software updates?
A: Customers who buy our machine,we can offer free upgrades software for you .

Customers' Cases



NeoDen in Exhibitions



Automatic 4 Head SMT Pick and Place Machine (NeoDen4) with Auto Rails 48 Feeders for PCB Assembly PCB BoardAutomatic 4 Head SMT Pick and Place Machine (NeoDen4) with Auto Rails 48 Feeders for PCB Assembly PCB BoardAutomatic 4 Head SMT Pick and Place Machine (NeoDen4) with Auto Rails 48 Feeders for PCB Assembly PCB BoardNeoDen in RussiaNeoDen in ArgentinaNeoDen in USA
