High Precision and Stable 10 Heating Zones Reflow Soldering SMT Reflow Oven

Shenzhen Jaguar Automation Equipment Co., Ltd.
  • Condition：New
  • Certification：CCC, ISO, CE
  • Warranty：12 Months
  • Automatic Grade：Automatic
  • Installation：Vertical
  • Name：Lead Free Reflow Soldering Equipment

Base Info

  • Model NO.：Jaguar R10,R10-N
  • Outside Dimension：6200 X 1350 X 1550mm
  • Weight：2200kg
  • Power Supply：5line, 3phase, 380V 50,60Hz
  • Control System：PC and PLC
  • Normal Power：11kw
  • Precision：High Precision
  • Demoulding：Automatic
  • Heating System：Electric
  • Transport Package：Wooden Box
  • Specification：CE
  • Trademark：Jaguar
  • Origin：China Shenzhen
  • HS Code：8515190000
  • Production Capacity：100 Sets,Month

Description



















GeneralDimension(L*W*H)6200×1350×1550mmWeight2800KGColorComputer grey
Parts List:
NO.Spares NameBrand Origin
1DisplayLenovoChina
2ComputerIndustrial China
3PLCSiemensGermany
4Contactor Germany
5  Temperature control moduleSiemensGermany
6Air switch Germany
7Power supplyMeanwellTaiwan
8Optoelectronic switchOmronJapan
9Inverter DeltaTaiwan
10Solid-state RelayCalro GavazziSwitzerland
11Heating wireHot SetGermany
12UPSSAGTARUSA
13Speed governorPanasonicJapan
14Conveyor motorPanasonicJapan
15High Temperature motorSanyueTaiwan
16MeltTsubakiJapan
17Double row chainKMCTaiwan
18Connecting shackleKMCTaiwan
19Solenoid ValveSMC Japan
20High temperature LineHotsetGermany
21Cooling MotorSanyueTaiwan
22Adjustable tooth boxPanasonicJapan
23Thermal relayCalro GavazziSwitzerland
