Data Building Network Wire Cable Extrusion Machine
HOOHA Co., LIMITED- Driven Type：Electric
- Condition：New
- Certification：CCC, ISO, CE
- Warranty：12 Months
- Screw：Single-Screw
- Transport Package：Wooden Package
Base Info
- Model NO.：HH-70,80,90
- Specification：CE ISO SGS
- Trademark：HOOHA
- Origin：Guangdong, Dongguan
- HS Code：8477209000
- Production Capacity：5sets,Month
Description
Note:"D" is the reading of the gauge.7. 8 Meters fixed water tank1) Cooling Length: 8 m2) Supported with 3 U-shaped racks, with the height being adjustable
3)American blow-off nozzle (2)
8.Capstan machine
1. Double-shaft driven: the capstan diameter is φ510 mm; the width of capstan groove is 20 mm , 4 grooves.
2. Capstan power: The motor for driving 5HP and converter for speed regulating, and in linkage with the main machine
3. Sealed stainless steel water tank, protecting the cooling water from splashing
4. Maximum linear velocity: 400 m/min ,four shift transmission
5. Falling wire device: prevent the capstan from sliding, thus ensuring a stable pull wire speed
6. Linear velocity wheel and linear velocity measure and control head of photoelectrons
9.10 meters wire storage rack
1. Type: horizontal, total length: 10m
2. Maximum accumulating wire length: 250 m
3. Accumulating wheel: Φ250 mm aluminum wheel
4. Motor power: 2HP worm wheel gear box
5. Tension control : 15 KG magnetic powder clutch + tension controller. After the accumulated wire tension is manually adjusted, the tension controller can automatically track the change of accumulated wire length, and then automatically adjust the tension.
6. Angle detection device: automatically control the take-up speed on basis of the accumulating wire length
7. Accumulated wire control cabinet the tension of accumulated wire is controlled by PID smart tension controller.
10.Spark Tester
0-15 KV, adjustable, AC voltage test, transformer capacity: 300 VA, breakdown sensitivity: 0.667 MA.
11. Measuring-meter platform
The surface of measuring-meter wheel shall be polished and be plated with hard chrome; a one-way bearing is installed in the measuring-meter wheel shaft to prevent the wheel from reverse rotation. The measuring-meter wheel is equipped with a rubber coated trace pressing wheel. The pressure of the trace pressing wheel can be adjusted, with the error of measuring meter being ±0.5%
12.Dual axle wire take up machine
1. Type: manually-operated replaceable take-up machine, for shaft-amounted or in-bundle purpose.
2. Applicable shaft diameter: PN500-630
3. Shaft assembling and disassembling: manually operated
4. Drive motor: The Siemens motor for driving 5HP, and converter for speed regulating.
5. Meter counter: 6-digit, double setting; reduce speed when a warning is forecasted; automatically stop when the specific meter is reached.
6. Traversing: a 30 rolling rings traverse drive is applied for traversing, with both the pitch and amplitude being adjustable.
7. Being controlled in linkage with the storage stand; automatic looping; non-stop when replacing the tray
8. Add 2 coiling machine heads for separate coiling the wire and cable
13.Electrical Control Box
1. 8 sections temperature table automatic temperature control system.
2 .The host and the traction are simultaneously controlled by the system.
3 .System Control of Individual Movement and Jointly Movement
4. Ammeter and Voltmeter
5 .Digital Wire Number Gauge
6 .Setting the automatic shutdown and automatic stop on breaking of a few meters
Interface for peripheral equipment: RS 485 communication connector
Spare Articles & Pieces
Our aim: To be a world-class supplier providing wire & cable manufacturing and using solution.
Our vision: To make wire & cable manufacturing and using more humanized.
Our target: More professional customer service, struggle for employees' dreams.
We are a Hong kong company, focusing on in-depth cooperation with Chinese leading manufacturers to provide advanced wire&cable solutions.
Exhibitions and Certificates
Customer Cases
FAQ
1. who are we?
We are based in Guangdong, China, start from 2017,sell to Africa(17.00%),Mid East(17.00%),Southeast Asia(16.00%),Eastern Asia(13.00%),South Asia(10.00%),South America(8.00%),Eastern Europe(4.00%),North America(3.00%),Northern Europe(3.00%),Southern Europe(3.00%),Oceania(2.00%),Western Europe(2.00%),Central America(2.00%). There are total about 5-10 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Drawing Machine,Stranding Machine,Cabling Machine,Extrusion Machine,Bunching Machine
4. why should you buy from us not from other suppliers?
1.10 year R&D working experience with over sea service 2.5 big LV/MV cable project over 5 million working experience 3.After service team has 30 country working experience 4. HOOHA team focus on the cable making and use solution supply chain.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery;
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese 6.After service
1. Delivery dates: 45 days
2. Payment: TT or L/C
3. Packing: Plastic packing to ensure the goods safety on the transportation.
4. Install and training service: 2 professional engineers who has over 5 years overseas install and cable manufacture training experience.5. After service phone number online
3)American blow-off nozzle (2)
8.Capstan machine
1. Double-shaft driven: the capstan diameter is φ510 mm; the width of capstan groove is 20 mm , 4 grooves.
2. Capstan power: The motor for driving 5HP and converter for speed regulating, and in linkage with the main machine
3. Sealed stainless steel water tank, protecting the cooling water from splashing
4. Maximum linear velocity: 400 m/min ,four shift transmission
5. Falling wire device: prevent the capstan from sliding, thus ensuring a stable pull wire speed
6. Linear velocity wheel and linear velocity measure and control head of photoelectrons
9.10 meters wire storage rack
1. Type: horizontal, total length: 10m
2. Maximum accumulating wire length: 250 m
3. Accumulating wheel: Φ250 mm aluminum wheel
4. Motor power: 2HP worm wheel gear box
5. Tension control : 15 KG magnetic powder clutch + tension controller. After the accumulated wire tension is manually adjusted, the tension controller can automatically track the change of accumulated wire length, and then automatically adjust the tension.
6. Angle detection device: automatically control the take-up speed on basis of the accumulating wire length
7. Accumulated wire control cabinet the tension of accumulated wire is controlled by PID smart tension controller.
10.Spark Tester
0-15 KV, adjustable, AC voltage test, transformer capacity: 300 VA, breakdown sensitivity: 0.667 MA.
11. Measuring-meter platform
The surface of measuring-meter wheel shall be polished and be plated with hard chrome; a one-way bearing is installed in the measuring-meter wheel shaft to prevent the wheel from reverse rotation. The measuring-meter wheel is equipped with a rubber coated trace pressing wheel. The pressure of the trace pressing wheel can be adjusted, with the error of measuring meter being ±0.5%
12.Dual axle wire take up machine
1. Type: manually-operated replaceable take-up machine, for shaft-amounted or in-bundle purpose.
2. Applicable shaft diameter: PN500-630
3. Shaft assembling and disassembling: manually operated
4. Drive motor: The Siemens motor for driving 5HP, and converter for speed regulating.
5. Meter counter: 6-digit, double setting; reduce speed when a warning is forecasted; automatically stop when the specific meter is reached.
6. Traversing: a 30 rolling rings traverse drive is applied for traversing, with both the pitch and amplitude being adjustable.
7. Being controlled in linkage with the storage stand; automatic looping; non-stop when replacing the tray
8. Add 2 coiling machine heads for separate coiling the wire and cable
13.Electrical Control Box
1. 8 sections temperature table automatic temperature control system.
2 .The host and the traction are simultaneously controlled by the system.
3 .System Control of Individual Movement and Jointly Movement
4. Ammeter and Voltmeter
5 .Digital Wire Number Gauge
6 .Setting the automatic shutdown and automatic stop on breaking of a few meters
Interface for peripheral equipment: RS 485 communication connector
Spare Articles & Pieces
- A set of die head (the customer shall provide relevant dimensions)
- A set of tools and toolbox is provided additionally
- A copy of Operation Instructions & technical document
