• Model NO.：NeoDen3V Standard
• Feeders：24
• Max Applicable Height：5mm
• Tape Width：8,12,16,24mm
• Vibration Feeder：1set
• Power Supply：220V, Convertible 110V
• Max Movement Speed：1m,S
• Vacuum Pump：3PCS
• Placement Head Qty：2PCS
• Transport Package：Fumigation-Free Wooden Box
• Specification：CE
• Trademark：NeoDen
• Origin：Zhejiang
• HS Code：84798962
• Production Capacity：200sets,M

Basic Info.

Model NO. NeoDen3V Standard Feeders 24 Max Applicable Height 5mm Tape Width 8/12/16/24mm Vibration Feeder 1set Power Supply 220V, Convertible 110V Max Movement Speed 1m/S Vacuum Pump 3PCS Placement Head Qty 2PCS Transport Package Fumigation-Free Wooden Box Specification CE Trademark NeoDen Origin Zhejiang HS Code 84798962 Production Capacity 200sets/M

Product Description

NeoDen3V Desktop Pick and Place Machine, 2 heads with vision--Standard Version-

It features dual head, 44 feeder slots, vision system and flexible positioning system, which is suitable for prototyping, small-medium batch
production with stable performance and affordable price.


Specification

Model	NeoDen3V(Standard)	NeoDen3V(Advanced)
Number Of Heads	2	2
Alignment	Vision	Vision
Rotation	±180°	±180°
Placement Rate	5000CPH(without vision);3500CPH(with vision)	5000CPH(without vision);3500CPH(with vision)
Feeder Capacity	Tape feeder:24(all 8mm)	Tape feeder:44(all 8mm)
	Vibration feeder: 0~5	Vibration feeder: 0~5
	Tray feeder: 5~10 (Customization supported)	Tray feeder: 5~10 (Customization supported)
Board Dimension	Maximum:320*420mm	Maximum:320*390mm
Component Range	Smallest components:0402	Smallest components:0402
	Largest components:TQFP144	Largest components:TQFP144
	Max height:5mm	Max height:5mm
Numbers Of Pumps	3	3
Placement Accuracy	±0.02mm	±0.02mm
Operate System	WindowsXP-NOVA	WindowsXP-NOVA
Power	160~200W	160~200W
Electricity Supply	110V/220V	110V/220V
Machine Size	820(L)*650(W)*410(H)mm	820(L)*680(W)*410(H)mm
Packing Size	1001(L)*961(W)*568(H)mm	1001(L)*961(W)*568(H)mm
Net Weight	55kg	60kg
Gross Weight	80Kg	85kg

√ NeoDen 3V Features

Full Vision 2 Head System
2 high-precision placement heads with ±180° rotation could satisfy the need of wide range components.

Patented Automatic Peel-box
Patented electromagnetic actuators, you don't need to get rid of the wasted nylon film manually, which saves you more time and effort.

Flexible PCB positioning
By using PCB support bars and pins, wherever you want to put the PCB and whatever the shape of your PCB is, all can be handled well

Integrated Controller
More stable performance and easier to do maintenance.


Manual Programming
Select "Chip list" to start manual programming.
Function: it's used to display footprints, coordinates, angles and sequences of components. You can choose to add these information
manually or import coordinates file directly.


Feeder Settings
All component's allocation should be operated in this interface, such as selection of nozzles and feeders, pick-up position, alignmentmethods, etc.



Accessories

1)Pick and Place Machine NeoDen3V-S: 1
2)PCB support bar: 4units
3)PCB support pin: 8units
4)Electromagnet: 1pack
 5)Needle: 2sets
6)Allen wren set: 1
7)Tool box: 1unit
8)Cleaning needle: 3units
9)Power cord: 1unit
10)Double side adhesive tape: 1set
11) Silicon tube: 0.5m
12)Fuse(1A): 2units
13)8G flash drive: 1unit
14)Reel holder stand:1set
15)Nozzle rubber 0.3mm: 5units
16)Nozzle rubber 1.0mm: 5units
17) Vibration feeder: 1unit

Payment & Delivery

1) Payment method: PayPal
2) The default delivery method is via DHL (door to door), unless specific requirement from customer.
3) Delivery time: 3 - 4 working days.

The guarantee period is 1 year from the time of purchase and lifelong service support as well as a long-term factory price supply.
NeoDen will provide online Q/A and troubleshooting support and technical advice service.

Why Choose NeoDen

>Main Items: PNP Machine, Reflow Oven, Stencil Printer and Accessories.

>Production Lines: 8 Sets Production Lines with 300 Sets Monthly Capacity

>R&D Team: 30 Engineers with more than 50 patents

>8 Oversea Agents: like India, Japan, Netherlands, South Korean, Iran, Turkey, Brazil and Chile, Neoden's sales network has covered more
than 110 countries.

> Strict QC: We have strictly QC system to ensure its stable and consistent quality,before shipping to you we will also for last QC to help you
control it.

Other 4-head/ 6-head/ 8-head pick and place machine assembly line for ref.:
