• Model NO.：T200C
• Warranty：12 Months
• Automatic Grade：Automatic
• Installation：Vertical
• Heating Supply：Full Hot-Air Convection
• Transmit Belt Width：300mm
• Temperature Control Segment：8 PCS
• Warm-up Time：25min
• Temperature Range：Room-Temperature -360 Degree
• Max PCB Size：360*230mm
• Conveyor Speed：0-1600mm,Min Adjustable
• Normal Working Power：4kw
• Dimension(L× W× H )(mm)：700(L) *460(W) *310(H)mm
• Temperature Control System：PC Control System, SSR Non-Contact Output
• Transport Package：Wooden Case or Package as Your Request
• Specification：CE ISO
• Trademark：Torch
• Origin：Beijing
• HS Code：8514109000
• Production Capacity：10 PCS ,Month
• Package size per unit product：75.00cm * 65.00cm * 49.00cm
• Gross weight per unit product：54.000kg

Basic Info.

Model NO. T200C Warranty 12 Months Automatic Grade Automatic Installation Vertical Heating Supply Full Hot-Air Convection Transmit Belt Width 300mm Temperature Control Segment 8 PCS Warm-up Time 25min Temperature Range Room-Temperature -360 Degree Max PCB Size 360*230mm Conveyor Speed 0-1600mm/Min Adjustable Normal Working Power 4kw Dimension(L× W× H )(mm) 700(L) *460(W) *310(H)mm Temperature Control System PC Control System, SSR Non-Contact Output Transport Package Wooden Case or Package as Your Request Specification CE ISO Trademark Torch Origin Beijing HS Code 8514109000 Production Capacity 10 PCS /Month

Packaging & Delivery

Package size per unit product 75.00cm * 65.00cm * 49.00cm Gross weight per unit product 54.000kg

Product Description

              Full Hot air Lead Free Reflow Oven/Soldering from Torch T200C
                                                                     Model:T200C

Type	T200C+/T200C
Max PCB size	360*230mm
Heating supply	Infrared ray + Hot air convection
Temperature range	Room-temperature -360 ºC
Welding time	3min ± 1min
Warm-up time	3min
Temperature accuracy	± 2 ºC
Temperature control system	PC control system, SSR non-contact output
Temperature control segment	40 segments, The segment can be set in computer according to the actual requirement.
Temperature-zone numbers	Single-zone and multi-segment
Temperature curve	It can be set, adjusted and tested according to the actual requirement.
Cooling system	Transverse flow equal cooling
Power supply	AC single-phase, 220V; 50Hz
compressed air	80psi(0.5Mpa)
Power supply	220V,50Hz,1KW ,Rated power : 3.8KW; Mean power:1.6kw
Weight	39 kg
Dimension	700(L) *460(W) *310(H)mm
