• Model NO.：SR-650
• Applicable Wire：2468, 2651, Multiple Electronic Wire
• Pins Number：2p-25p( Customized)
• Required Cable Length：Min. 60mm
• Required Wire Split Length：25-30mm
• Required Stripping Length：0-5mm
• Driving Motor：Delta Servo Motor
• Control Mode：Touch Screen, PLC Control
• Efficiency：12000 Terminals Per Hour
• Air Source：0.3-0.5MPa
• Voltage：AC220V 50,60Hz
• Weight：200kg
• Transport Package：Plywood Case
• Specification：780*440*1300mm
• Trademark：Sinrad
• Origin：China
• HS Code：8479819000
• Production Capacity：50 Sets,Month

Specification: ModelSR-650Crimping Force1.5t (Customized)Applicable TerminalContinuous TerminalApplicable wire2468, 2651, multiple electronic wirePins number2p-25p( customized)Required cable lengthmin. 60mmRequired wire split length25-30mmRequired stripping length0-5mmDriving motorDelta servo motorControl modeTouch screen, PLC controlEfficiency12000 terminals per hourVoltageAC220V 50/60HZAir source0.3-0.5MPaWeight200kg Features:

1. The use of high-quality servo motors greatly reduces the noise during mechanical operation.
2. Through the miniaturization of components and the integration of mechanisms, air consumption and electricity consumption are greatly reduced.
3. Able to automatically set the wire model, wire P number
4. It can automatically set the distance from the straight line to the punching. The position accuracy can be accurate to 0.01.
5. Ribbon Cable crimping machine integrating high quality, high efficiency and multi-function.

Pictures:



Contact:


 FAQ:

1 Price terms

The price is based on EWX/FOB, if you request CFR or CIF, please give us your delivery port, and we will give you CFR price or CIF price for reference.

2 Can I send samples to check the machine quality.

Yes, welcome to send us samples. We would be pleased to show you trial testing base on your samples.

3 How to learn the machine?

1) Offer free technology learning support in our factory

2) Provide detail user manual with detail video illustration

3) Support engineer service at site if clients asking for

4 How about the lead time and delivery time of order?

Standard model, can be ship out within 3~7days after confirmed order and deposit.

Customized model, normally lead time is 10~30 days, after confirmed all order detail deposit and got samples.

Company info:
Sinrad Technology Co.,Ltd, specialized in automation machine, customizing and manufacturing cable processing(cutting, striping, twisting, crimping, soldering, housing inserting, winding, binding, testing, etc.) machine, automatic soldering machine, intelligent soldering machine, and other production equipment.
