Automatic Transformer High Voltage Coil Winding Machine

Nantong Zhenhuan Trade Co., Ltd.
  • Voltage：380V
  • Warranty：12 Months
  • Suitable Round Coil Od：Max. 600mm
  • Rectangular Coil Diagonal Length：Max. 1000mm
  • Suitable Flat Conductor Size：Max. 3X12mm
  • Suitable Round Conductor Size：0.3-3mm

Base Info

  • Model NO.：GXR
  • Suitable Transformer Coil Weight：Max. 500kg
  • Suitable Transformer Coil Width：Max. 1000mm
  • Winding Speed：0~200rpm
  • Auto Conductor Guiding Control：PLC Control
  • Traversing Pitch：Min. 0.01mm
  • Precision：Precision
  • Automatic Grade：Automatic
  • Condition：New
  • Customized：Customized
  • Automatic：Automatic
  • Certification：ISO
  • Transport Package：Wooden Case
  • Specification：2500 x 2000 x 2000mm
  • Trademark：Zhenhuan
  • Origin：China
  • Production Capacity：100 Sets Per Year

Description

ItemDataMandrel height to ground850mmSuitable coil lengthMax. 1000mmSuitable coil IDMin. 80mmSuitable coil ODMax. 600mmSuitable coil weightMax. 500kgWinding moment600N·MWinding speed0-200rpm, inverter control adjustableAutomatic conductor traversing deviceMin. pitch 0.01mmSuitable rectangular conductorMax. 3mm x 12mmSuitable round conductor0.3~3mmMain driving motor power4kW, inverter controlConductor traversing servo motor220W We, Nantong Zhenhuan Trade Co., Ltd. has been in transformer making machines business for more than 16 years. We are certified by TUV, BV and SGS with good credit and reputation from customers all over the world. We can provide you good quality automatic transformer coil winding machines as well as good after-services.Automatic Transformer High Voltage Coil Winding MachineAutomatic Transformer High Voltage Coil Winding MachineAutomatic Transformer High Voltage Coil Winding MachineAutomatic Transformer High Voltage Coil Winding MachineAutomatic Transformer High Voltage Coil Winding MachineAutomatic Transformer High Voltage Coil Winding MachineAutomatic Transformer High Voltage Coil Winding MachineAutomatic Transformer High Voltage Coil Winding MachineAutomatic Transformer High Voltage Coil Winding Machine

 Kindly please visit our website jygoldland.en.made-in-china.com for more automatic transformer coil winding machines and other transformer making machines.
