• Model NO.：JAGUAR R10
• Number of Cooling Zones：up 3 Bottom 3
• Length of Heating Zones：3900mm
• Heating Mode：Hot Air
• Cooling Mode：Air Oven:Forced Air
• Max. Width of PCB：450mm
• Transmission Type：Mesh and Chain
• Fixed Rail Side：Front Rail Fixed(Option: Rear Rail Fixed)
• Power Supply：5 Line 3 Phase 380V 50,60Hz
• Conveyor Speed：0-2000mm,Min
• Transport Package：Wooden Box
• Specification：5710*1350*1490mm
• Trademark：JAGUAR
• Origin：China
• HS Code：8501101000
• Production Capacity：100 Sets,Month

JAGUAR R10



Heating SystemNumber of heating zonesUP 10/BOTTOM 10Number of cooling zonesUp 3 bottom 3Length of heating zones3900mmHeating modehot airCooling ModeAir Oven:Forced airExhaust Volume10m³/min * 2 exhausts




Conveyor SystemMax. Width of PCB450mmMesh belt width500mmTransmission DirectionL→R(or R→L)Transmission Net Height900±20mmTransmission typeMesh and chainRange of rail width0-450mmConveyor speed0-2000mm/minAuto/manual LubricationstandardFixed rail sideFront rail fixed(option: rear rail fixed)Components highTop and bottom 25mm







Control systemPower supply5 line 3 phase 380V 50/60HzTotal power50kwStarting power48kwNormal power consumption10KWWarming timeAbout 20 minsTemp. setting rangeRoom temperature-300ºCTemp. control methodPID close loop control & SSR drivingTemp. control precision±1ºCTemp. deviation on PCB±2ºC

Data storage	Process Data and status storage(80GB)
Nozzle plate	Aluminum Alloy Plate
Abnormal Alarm	Abnormal temp. (extra-high/extra-low temp.)
Board dropped alarm	Tower light:Yellow-warming, Green-normal, Red-abnormal
Dimension(L*W*H)	5600×1400×1550mm
Weight	2150KG
Color	Computer gray

Introduction:
1.Windows XP system with English and Chinese is easy to learn how to operate and can be change any time.
2. The digital control system adopted with PLC and Modular circuit to stabilized and accurate of repetitive precision.
3. Intelligent diagnosis system (IDS) has the function of trouble remind, alarm, list-out and saving data.
4. Temperature and blower speed can be controlled independently, to meet the high-precision requirements.
5.Effective heating zone length, the heat conduction in full uniform distribution, greatly improving the heating efficiency.
6.Forced cooling system with efficient cooling speed suits all different kinds of lead-free soldering paste.
7.PLC and PID closed loop control to achieve high precision temperature control and repeatable profiles.
8. Standard 8 couples of up and down zones with patented air management system to make hot air convection more efficient and faster thermal compensation.
9.The rail is dealt with hardened process to make it more stability.
10.The rail width can be adjusted by manual.(option:automatically by SPG gear motor).
11.Chain Rails will be lubricated by central oil reservior device ,controlled by computer.
12.Strong software system can save all settings and can print all the data and profiles through PC.
13.With flux collecting system to keep inside zones clean and ensures more environmental emission.
14.Nitrogen with machine is option.
