• Model NO.：XJ-30,40,50,60,70,80,90,100,120MM
• Extrusion Material：PVC,PE
• Power：50HP
• Highest Output：180kg,H
• Highest Wire Speed：300m,Min
• Capstan Power：7.5HP
• Temperature Control：5+3 Segments (Body+ Head)
• Usage：Power Wire,Computer Wire etc Insulation Extrusion
• Precision：High Precision
• Demoulding：Automatic
• Heating System：Electric
• Function：High Temperature Resistance
• Mould Life：300, 000-1, 000, 000 Shots
• Customized：Customized
• Transport Package：Wooden Box,Pallet
• Specification：cable machine
• Trademark：Newtopp
• Origin：Chinese Mainland
• HS Code：8479400000
• Production Capacity：60 Sets,Month

Equipment modelXJ-70XJ-80XJ-90XJ-120Usage:Power Wire/ computer wire/ building wire/data wire/ high frequency wire insulation/jacket sheath extrusionWire specification1.5-12mm2-20mm3-25mm10-50mmExtrusion materialPVC/SRPVC/LHNF/PE/PP/PU etcScrew parameterL/D ratio:26:1, compression ratio: 2.7-3.2, Screw material:38CrMoAIA, Vacuum heating treatment, Surface Grinding Polishing chromium platingTemperature control segments (body+head)5+35+36+36+3Power40HP50HP60HP100HPThe highest output140KG/H180KG/H240KG/H360KG/HThe highest wire speed400M/min300M/min250M/min180m/minMovable water tankExtension type movable tank, movable lenth is 300mm, over length 1.5m with single segment water dryer. Or as requirementLength of U type cooling tank7.5M7.5M10M15MAccumulate wheel parameter(11+10 grooves)250300400500Capstan power5HP7.5HP7.5HP15HPpay off typeHow may shafts, active with moter and passive without moter just as requestTake up TypeAs request

B.50+35 core wire extruderExtruder material: PVC/PE/SRPVCWire specification:AWG30-AWG24,0.8-2.8The highest wire speed:1000m/min Semi-auto take up(depends on wire dia);Use for high-speed insulation extrusion for PVC/PE/secondary colour wire and Lan cable(CAT5, CAT5E, CAT6, CAT6A, CAT7) insulation extruderOperating Direction:left or right is allowed (For example:if the take up direction is right, it will call"right hand machine" when face electric box.);Dosage of air-pressure:18m³/HrScrew parameter: L/D ratio:26:1, compression ratio: 2.7-3.2, Screw material:38CrMoAIA, Vacuum heating treatment, Surface Grinding Polishing chromium platingPay off type: as requestTake up type: as requestCentre-height:1000mm;ø50mm extruder host+35mm stripping extruderVoltage:Three-phase 410V-450 50HZ or as request
