0.08-0.45mm Bare Copper Wire Insulated Core Cable Wire Twisting Bunching Stranding Machine

Kunshan Fuchuan Electrical and Mechanical Co., Ltd.
  • After-sales Service：12months
  • Driven Type：Electric
  • Condition：New
  • Certification：ISO, CE
  • Warranty：12 Months
  • Automatic Grade：Automatic

Base Info

  • Model NO.：FC-500B-1
  • Mould Life：>1,000,000 Shots
  • Type：High-speed Stranding Machine
  • Fit for Wire：Bare Copper Wire,Tinned Wire,Enamelled Wire
  • Fit for Take up Bobbin：Diameter 500
  • Diameter of Wire：0.08-0.45mm
  • Main Motor Power：5.5kw
  • Magnetic Powder Clutch：1.2kgf
  • Max Rotating Speed：3000rpm
  • Transport Package：Simply Packed
  • Specification：ISO9001
  • Trademark：Fuchuan
  • Origin：China
  • HS Code：8479111000
  • Production Capacity：50sets,Month

Description

Equipment modelsFC-500B-1Twisting usageIt is applied to the twisting of aerospace, medical equipment, cellphone and ultra conductor(above seven pcs of bare copper wires, tinned wires, silver jacketed wires and enameled wires),double twisting for core wires.Single wire dia(mm)φ0.08-φ0.45Stranding section area (mm²)0.05-2.5 Core wire single wire diaφ0.5-φ1.5Core wire stranding outer diaφ1.0-φ3.5Pitch(mm)6.3-52.3(24zones)Direction of layOptional for right or leftOuter dia*bore*outer widthφ500*φ56*375Max rotating speed3000(6000twist)Main motor power5.5KWInverter power5.5KWTension control methodTouch screen +PLC+ magnetic powder clutch, it may ensure the constant tension from empty bobbin to full bobbinMagnetic powder clutch1.2kgfProtectionMachine will automatically brake when wire inside and outside is broken, the machine will automatically stop when the preset length is arrived.Brake modeElectromagnetic brakeTraversing methodRolling ring drive units, winding pitch and breadth are adjustableOperation modeTouch screen operationDimension(mm)2680L*1250W*1500H
