• Model NO.：WL-J70
• Wire Size：0~70sq mm
• Cutting Length：1-100000mm
• Stripping Length：Head: 0~300mm, Tail: 0~150mm
• Wire Guide Diameter：20mm
• Display Screen：English LCD Screen
• Productivity：1500~2500PCS,H
• Drive Method：12 Wheels
• Dimension：700*640*480mm
• Weight：100kg
• Cutting Length Tolerances：(0.002*L)mm
• Transport Package：70*64*48cm
• Specification：100kg
• Trademark：Crown
• Origin：China
• HS Code：8479819000
• Production Capacity：1000set,Month

Display Method:7 inches color touch screen+PLCApplicable wires:multi-stranded copper wire,coaxial cable, sheath cable, etc.Wire cross-section:BVR2.5 0~70mm2 (BV35 mm2, sheath cable outer diameter Max.18mm)Wire guide pipe diameter:Max.20mmCutting length:0~100mStripping lengh:head: 0~300mm(head length longer than 500mm, can add pierced device), tail: 0~150mmCutting tolerance:±(0.002mm*L)(L= cutting length)Memory function:can store Max. 100 groups of programsDrive method:12 wheels drive, Synchronous belt feedingBlade material:imported high speed steelPower supply:220/110V, 50/60hzPower rating:800wStripping speed:1500~2500pcs/HDimension:700*640*480mmWeight:about 100kgs

Chinese / English LCD Screen

Application




Machine:





Packing & Shipping:

For small and light products packed by cartons,for large and heavy products packed by wooden

Company info:






Our Services

1, One year guarantee for the whole machine except blade and belt.

2, 24 hours technical support by email.

3, User-friendly English software and user manual.

-Purchase guidance

If you are not sure which model is the best option within your budget, please send us the parameter or wire, it's our pleasure to make a recommendation and comparison models

to you.

---After Sale Service

Don't worry, we are here to help. Crown provides lifetime after sale support to our customers including operation guidance, parts replacement, maintenance support. Just feel free to contact us!

--- Technical Support

In some cases, professional technical support will be needed, such as parameter meter set-up

 for difficult-to process wires. Crown engineers are here for your assistance.

---Others

Compensation: If any unqualified product is found, we'll pay the compensation or send newly qualified products to customers.

Maintenance & Repair: In case of any maintenance or repair need, we'll help to find out the problem and offer relative guidance.
