• Wire Spec：3-10 mm
• Wire Speed：Max: 200meters,Min
• Extrusion Capacity：120 Kg,H
• Bobbin Size：500-800 mm
• Motor：Siemens
• Inventor：Yaskawa
• Main Power：85 Kw
• Material：PE, PVC
• Voltage：380V or Customized
• L/D of Screw：25:1
• Transport Package：Plastic Packing
• Specification：30*20m
• Trademark：hooha
• Origin：Donguan, China
• HS Code：8479400000
• Production Capacity：3 Set,Month

No.ItemsQuantity1500 Bunching machine1 set2Pay off stand multi-core copper wire1 set


Parameters:

No.ItemsValue1Single wire diameterØ0.08mm-Ø0.30mm2Stranding area0.3mm2-2.5 mm23Stranded wire length calculationHow many meters per minute = twisting distance *2/1000* twisting bow speed per minute4Twisting pitch5.66 - 39.37mm5Rotation speed of arched bandMax: 2200RPM.6Spindle lubricationUse manual grease gun to inject oil




2. HH-E-65 Silicone Cable Extrusion Machine

Application:
This silicone cable extrusion line is applicable for insulation and sheathing extruding for single, 2 cores, 3 cores silicone cables such as power cables, medical cables, control cables etc.

Components:

No.ItemsFeatures1400-630 active pay-off stand1 set25-wheel Straightening device1 set3Copper wire preheating machine1 set465 Silicone extrusion machine with vacuum pump1 set5PLC electric control box1 set6Diameter tester1 set720m Electric heating curing chamber1 set8High speed printing machine1 set99 meters accumulator stand1 set10Dual wheels Capstan1 set11Meter counter1 set12High frequency spark tester1 set13Powder machine1 set14Double shaft take-up machine1 set15Display board1 set16Accessories


Parameters:

No.ItemsFeatures1Inlet Wire Diameter0.3-5.0mm2Finished Wire Diameter1.8-8.0mm4Extrusion SpeedMax 80 m/min5Extrusion Capacity60 kg/h6Installed Capacity65 kva7Voltage380KV, can be customized8Weight3500 kg9Measurement (L*W*H)18*2*2 m10Workers recommendation3 workers
