Manufacturing Equipment for Electrical & Electronic Product

Smart Desktop Hot Wind Reflow Oven with 6 Temperature Zones Leadfree for SMT Production Line

Zhejiang NeoDen Technology Co., Ltd.
  • After-sales Service:1 Year Warranty
  • Condition:New
  • Certification:CE
  • Warranty:12 Months
  • Automatic Grade:Automatic
  • Installation:Desktop

Base Info

  • Model NO.:IN6
  • Application:Lead, Lead-Free Soldering
  • Rated Power:2kw
  • Heating Zone:Upper3, Bottom3
  • Heating Type:Nichrome Wire and Aluminum Alloy Heating
  • Conveyor Speed:15-60cm,Min, 6-23 Inch,Min
  • Standard Heating Height:30mm
  • Temperature Range:Room Temperature-300 Degree Celsius
  • Temperature Accuracy:+,-0.2 Degree Celsius
  • Temperature Distribution Deviation:+,-1 Degree Celsius
  • Soldering Width:260mm (10 Inches)
  • Chamber Process Length:680mm (26.8 Inches)
  • Heat-up Time:15min
  • Machine Dimension:1020X507X350mm (Lxwxh)
  • Transport Package:Heavy-Duty Carton
  • Specification:CE
  • Trademark:Neoden
  • Origin:Zhejiang, Cn
  • HS Code:8515809090
  • Production Capacity:200sets,M

Description

Overview Customers' Cases



NeoDen in ExhibitionsFactory TourSmart Desktop Hot Wind Reflow Oven with 6 Temperature Zones Leadfree for SMT Production LineSmart Desktop Hot Wind Reflow Oven with 6 Temperature Zones Leadfree for SMT Production LineSmart Desktop Hot Wind Reflow Oven with 6 Temperature Zones Leadfree for SMT Production Line
