• Model NO.：XJ-50,60,70,80,90,100,110,120MM
• Extrusion Material：PVC,PE
• Power：50HP
• Highest Output：180kg,H
• Highest Wire Speed：300m,Min
• Capstan Power：7.5HP
• Pay off Type：as Requirement
• Temperature Control：5+3 Segments (Body+ Head)
• Usage：Power Wire,Computer Wire etc Insulation Extrusion
• Precision：High Precision
• Demoulding：Automatic
• Function：High Temperature Resistance
• Mould Life：300, 000-1, 000, 000 Shots
• Automatic Grade：Automatic
• Customized：Customized
• Transport Package：Wooden Box,Pallet
• Specification：cable machine
• Trademark：Newtopp
• Origin：Chinese Mainland
• HS Code：8479400000
• Production Capacity：60 Sets,Month

Equipment modelXJ-70XJ-80XJ-90XJ-120Usage:Power Wire/ computer wire/ building wire/data wire/ high frequency wire insulation/jacket sheath extrusionWire specification1.5-12mm2-20mm3-25mm10-50mmExtrusion materialPVC/SRPVC/LHNF/PE/PP/PU etcScrew parameterL/D ratio:26:1, compression ratio: 2.7-3.2, Screw material:38CrMoAIA, Vacuum heating treatment, Surface Grinding Polishing chromium platingTemperature control segments (body+head)5+35+36+36+3Power40HP50HP60HP100HPThe highest output140KG/H180KG/H240KG/H360KG/HThe highest wire speed400M/min300M/min250M/min180m/minMovable water tankExtension type movable tank, movable lenth is 300mm, over length 1.5m with single segment water dryer. Or as requirementLength of U type cooling tank7.5M7.5M10M15MAccumulate wheel parameter(11+10 grooves)250300400500Capstan power5HP7.5HP7.5HP15HPpay off typeHow may shafts, active with moter and passive without moter just as requestTake up TypeAs request                                   50+35 core wire extruderExtruder material: PVC/PE/SRPVCWire specification:AWG30-AWG24,0.8-2.8The highest wire speed:1000m/min Semi-auto take up(depends on wire dia);Use for high-speed insulation extrusion for PVC/PE/secondary colour wire and Lan cable(CAT5, CAT5E, CAT6, CAT6A, CAT7) insulation extruderOperating Direction:left or right is allowed (For example:if the take up direction is right, it will call"right hand machine" when face electric box.);Dosage of air-pressure:18m³/HrScrew parameter: L/D ratio:26:1, compression ratio: 2.7-3.2, Screw material:38CrMoAIA, Vacuum heating treatment, Surface Grinding Polishing chromium platingPay off type: as requestTake up type: as requestCentre-height:1000mm;ø50mm extruder host+35mm stripping extruderVoltage:Three-phase 410V-450 50HZ or as request Dear my friend,
       Good day to you!
       This is Delicia Xing from Dongguan NewTopp Electrical Machinery Co.,Ltd.
About coiling machine,it should be written on the top:
     Customized products are what we reccomend.We prepare three (Of course,even more) combination arrangement to meet different wire demands and diversified needs of our customer.Our coiling/winding machine can be applied for coiling/rewinding of all kinds of wire or cable such as Lan cable,Power cable,HDMI etc.
     Hope you can read through our company introduction below. However,if you are in urgent need of wire/cable equipment,I also prefer to receive your name card , pictures of original products and product that you want to achieve at first and get exact inquiry from you.Thank you so much! ∧ω∧
       Followings will let you have a general idea of us:
       Our company  running for over ten years in designing and manufacturing automatic wire&cable equipment locates in the  manufacturing center--Humen Town,DongGuan City,GuangDong Province,China.We have mature production technology  applying for whole set production line of HDMI,LAN cable,power wire,USB3.0/3.1,Car wire,data wire,high frequency wire,earphone wire etc.from extrusion,twisting,taping,cutting,coiling/rewinding to packing etc.


       Our strength:
1.Factories:
Two factories are in wire&cable equipment manufacturing center distributing in south and north China.
2. Expos:
Every year we regularly attended over 6 international wire&cable Expos home and overseas.(Russian(March),Germany(April),ShangHai(September),Thailand(September),India(November) etc.)
3.Output:
The annual output is around 600 sets. Our annual sales in 2019 has reached up to one hundred million.
4.HR:
NewTopp team has been up to 200 staffs until 2020,and the quantity is still rising.
5.Technology:
As brain of NewTopp,it provides continuous software system support and technological update . Every year we invite foreign professional engineers from our partners to attend annual technical seminar.
6.Overseas Market:
We have got a wide market in southeast Asia.We mainly sold our equipment to Russia, Iran, Italy, Turkey, South Korea, Japan,Vietnam, India, Saudi Arabia ,Indonesia  ect.
7.Partners:
Two of our long-term cooperative partners are:
Luxshare-ICT: ranks the 74th on the list of 2020 market capitalization top 500 in China)
BELDEN: Belden Inc.&Cable Design Technologies Corp) .
  I am looking forward to hearing from you!
Best regards,
