SMT Lead-Free Hot Air Reflow Soldering with 10 Heating Zones

Shenzhen Jaguar Automation Equipment Co., Ltd.
  • Condition：New
  • Certification：CE
  • Warranty：12 Months
  • Automatic Grade：Automatic
  • Installation：Vertical
  • Number of Heating Zones：up 10, Bottom 10

Base Info

  • Model NO.：F10
  • Number of Cooling Zones：2(up 2, Bottom 2)
  • Length of Heating Zones：3890mm
  • Max. Width of PCB：400mm
  • Mesh Belt Width：450mm
  • Transmission Type：Mesh and Chain
  • Conveyor Speed：0-2000mm,Min
  • Fixed Rail Side：Front Rail Fixed(Option: Rear Rail Fixed)
  • Power Supply：5 Line 3 Phase 380V 50,60Hz
  • Weight：2300kg
  • Transport Package：Wooden Box
  • Specification：5800*1320*1490mm
  • Trademark：JAGUAR
  • Origin：China
  • HS Code：8501101000
  • Production Capacity：100 Sets,Month

Description

















GeneralDimension(L*W*H)5800*1320*1490mmWeight2300kgColorComputer gray SMT Lead-Free Hot Air Reflow Soldering with 10 Heating ZonesSMT Lead-Free Hot Air Reflow Soldering with 10 Heating ZonesSMT Lead-Free Hot Air Reflow Soldering with 10 Heating ZonesSMT Lead-Free Hot Air Reflow Soldering with 10 Heating ZonesSMT Lead-Free Hot Air Reflow Soldering with 10 Heating ZonesSMT Lead-Free Hot Air Reflow Soldering with 10 Heating ZonesSMT Lead-Free Hot Air Reflow Soldering with 10 Heating Zones
