Top Lead-Free Hot Air Reflow Oven with R10 Heating Zones
Shenzhen Jaguar Automation Equipment Co., Ltd.- Condition：New
- Certification：CE
- Warranty：12 Months
- Automatic Grade：Automatic
- Installation：Vertical
- Number of Heating Zones：up 10,Bottom 10
Base Info
- Model NO.：JAGUAR R10
- Number of Cooling Zones：up 3 Bottom 3
- Length of Heating Zones：3900mm
- Heating Mode：Hot Air
- Cooling Mode：Air Oven:Forced Air
- Max. Width of PCB：450mm
- Transmission Type：Mesh and Chain
- Fixed Rail Side：Front Rail Fixed(Option: Rear Rail Fixed)
- Power Supply：5 Line 3 Phase 380V 50,60Hz
- Conveyor Speed：0-2000mm,Min
- Transport Package：Wooden Box
- Specification：5710*1350*1490mm
- Trademark：JAGUAR
- Origin：China
- HS Code：8501101000
- Production Capacity：100 Sets,Month
Description
JAGUAR R10
Heating System Number of heating zones UP 10/BOTTOM 10 Number of cooling zones Up 3 bottom 3 Length of heating zones 3900mm Heating mode hot air Cooling Mode Air Oven:Forced air Exhaust Volume 10m³/min * 2 exhausts
Conveyor System Max. Width of PCB 450mm Mesh belt width 500mm Transmission Direction L→R(or R→L) Transmission Net Height 900±20mm Transmission type Mesh and chain Range of rail width 0-450mm Conveyor speed 0-2000mm/min Auto/manual Lubrication standard Fixed rail side Front rail fixed(option: rear rail fixed) Components high Top and bottom 25mm
Control system Power supply 5 line 3 phase 380V 50/60Hz Total power 50kw Starting power 48kw Normal power consumption 10KW Warming time About 20 mins Temp. setting range Room temperature-300ºC Temp. control method PID close loop control & SSR driving Temp. control precision ±1ºC Temp. deviation on PCB ±2ºC
Introduction:
1.Windows XP system with English and Chinese is easy to learn how to operate and can be change any time.
2. The digital control system adopted with PLC and Modular circuit to stabilized and accurate of repetitive precision.
3. Intelligent diagnosis system (IDS) has the function of trouble remind, alarm, list-out and saving data.
4. Temperature and blower speed can be controlled independently, to meet the high-precision requirements.
5.Effective heating zone length, the heat conduction in full uniform distribution, greatly improving the heating efficiency.
6.Forced cooling system with efficient cooling speed suits all different kinds of lead-free soldering paste.
7.PLC and PID closed loop control to achieve high precision temperature control and repeatable profiles.
8. Standard 8 couples of up and down zones with patented air management system to make hot air convection more efficient and faster thermal compensation.
9.The rail is dealt with hardened process to make it more stability.
10.The rail width can be adjusted by manual.(option:automatically by SPG gear motor).
11.Chain Rails will be lubricated by central oil reservior device ,controlled by computer.
12.Strong software system can save all settings and can print all the data and profiles through PC.
13.With flux collecting system to keep inside zones clean and ensures more environmental emission.
14.Nitrogen with machine is option.
Heating System
Conveyor System
Control system
| Data storage | Process Data and status storage(80GB) |
| Nozzle plate | Aluminum Alloy Plate |
| Abnormal Alarm | Abnormal temp. (extra-high/extra-low temp.) |
| Board dropped alarm | Tower light:Yellow-warming, Green-normal, Red-abnormal |
| Dimension(L*W*H) | 5600×1400×1550mm |
| Weight | 2150KG |
| Color | Computer gray |
1.Windows XP system with English and Chinese is easy to learn how to operate and can be change any time.
2. The digital control system adopted with PLC and Modular circuit to stabilized and accurate of repetitive precision.
3. Intelligent diagnosis system (IDS) has the function of trouble remind, alarm, list-out and saving data.
4. Temperature and blower speed can be controlled independently, to meet the high-precision requirements.
5.Effective heating zone length, the heat conduction in full uniform distribution, greatly improving the heating efficiency.
6.Forced cooling system with efficient cooling speed suits all different kinds of lead-free soldering paste.
7.PLC and PID closed loop control to achieve high precision temperature control and repeatable profiles.
8. Standard 8 couples of up and down zones with patented air management system to make hot air convection more efficient and faster thermal compensation.
9.The rail is dealt with hardened process to make it more stability.
10.The rail width can be adjusted by manual.(option:automatically by SPG gear motor).
11.Chain Rails will be lubricated by central oil reservior device ,controlled by computer.
12.Strong software system can save all settings and can print all the data and profiles through PC.
13.With flux collecting system to keep inside zones clean and ensures more environmental emission.
14.Nitrogen with machine is option.
