• Model NO.：M8
• Number of Heating Zones：up 8,Bottom8
• Length of Heating Zones：2900mm
• Heating Mode：Hot Air
• Cooling Mode：Force Air
• Cooling Zones：up 1 Bottom 1
• Max. Width of PCB：350mm
• Mesh Belt Width：400mm
• Transmission Net Height：880±20mm
• Transmission Type：Mesh and Chain
• Transport Package：Wooden Box
• Specification：4600*1100*1490mm
• Trademark：JAGUAR
• Origin：China
• HS Code：85151900
• Production Capacity：30 Sets,Month

Model

JAGUAR M8





Heating System

Number of heating zones

UP 8/BOTTOM8

Length of heating zones

2900MM

Heating mode

hot air

Cooling Mode

Force air

Cooling zones

Up 1 bottom 1











Conveyor System

Max. Width of PCB

350mm

Mesh belt width

400mm

Transmission Direction

L-R(or R-L)

Transmission Net Height

880±20mm

Transmission type

Mesh and chain

Range of rail width

0-300mm

Conveyor speed

0-1500mm/min

Auto/manual Lubrication

standard

Upper hood method

Manual(option:auto)

Fixed rail side

Front rail fixed(option: rear rail fixed)

Components high

Top and bottom 25mm

















Control system

Power supply

5line 3phase 380V 50/60Hz

Total power

28kw

Starting power

26kw

Normal power consumption

4KW

Warming time

About 20 mins

Temp. setting range

Room temperature-300ºC

Temp. control method

PLC & PC

Temp. control precision

±1ºC

Temp. deviation on PCB

±2ºC

Data storage

Process Data and status storage(80GB)

Nozzle plate

Aluminum Alloy Plate

Abnormal Alarm

Abnormal temp. (extra-high/extra-low temp.)

Board dropped alarm

Tower light: Yellow-warming, Green-normal, Red-abnormal



General

Dimension(L*W*H)

4600*1100*1490mm

Weight

1000KG

Color

Computer gray

Packaging & Shipping

                                    vaccum packing + wood
