Lead Free Reflow Oven for Small Production (A6)

Shenzhen Jaguar Automation Equipment Co., Ltd.
  • Condition：New
  • Certification：ISO, CE
  • Warranty：12 Months
  • Automatic Grade：Automatic
  • Heating Zones：Up6,Bottom6
  • Length of Heating Zones：2400mm

Base Info

  • Model NO.：Jaguar A6
  • Cooling Zone：1
  • Power Supply：5 Line, 3phase, 380V 50,60Hz
  • Heating Method：up: Hot Air ; Bottom: IR
  • Precision：Normal Precision
  • Demoulding：Automatic
  • Heating System：Electric
  • Function：High Temperature Resistance
  • Mould Life：>1, 000, 000 Shots
  • Transport Package：Wooden Case
  • Specification：CE
  • Trademark：Jaguar
  • Origin：Shenzhen, China
  • HS Code：85151900
  • Production Capacity：100PCS,Month

Description

5 line 3 phase 380V 50/60 HZWarming timeApprox. 20 minsHeating timeUp:hot air; bottom: IRTemperature setting rangeRoom temp. -350 Degrees CelsiusControl systemPID+SSR/PLC+PCTemperature control methodPID Close loop control&SSR DrivingTemperature control precision±1.0 Degrees CelsiusTemperature deviation on PCB±2.0 Degrees CelsiusData storageProcess data and status storage(80 GB)Abnormal alarmAbnormal temp.(extra-high/extra -low temperature)Board dropped alarmTower light:yellow-warming;green-normal;red-abnormalMax. Width of pcb320mmConveyor height880±20mmConveyor directionL-R/R-LConveyor speed range0-1500mmPcb transmission agentMeshNormal power4.5KWStart-up power18KW
