• Model NO.：Jaguar F8
• Cooling Zones：Up2,Bottom 2
• Heating Length：3100mm
• Heating Mode：Hot Air
• Cooling Mode：Forced Air Cooling
• Precision：High Precision
• Demoulding：Automatic
• Heating System：Electric
• Function：Lubrication
• Mould Life：>1, 000, 000 Shots
• Transport Package：Wooden Case
• Specification：CE
• Trademark：Jaguar
• Origin：Shenzhen, China
• HS Code：85151900
• Production Capacity：100PCS,Month

ModelJaguar F8GENERALDimension(L*W*H)5050*1320*1490mmweightApprox. 1850KG/1950KGnumber of heating zonesUp8 /Bottom8length of heating zones3120mmnumber of cooling zonesup2(cool air conversion)exhaust volume10m³/min ×2 ExhaustsConveyor systemrails structuresubsection integrated typeMax. width of PCB400mm(option 460mm)range of rail width50-400mm(option 50-460mm)components clearancetop 30mm/bottom 25mmconveyor directionL-R(Option R-L)fixed rails sideFront Rail Fixed(Option: Rear Rail Fixed)PCB transmission modeAir-Reflow=chain+mesh,
N2-Reflow=Chain+mesh(option)conveyor height900±20mmconveyor speed range300-2000mm/minauto/manual lubricationstandardcontrolling systemElectric supply3 phase 380V 50/60 HZ(3 phase 220 V 50/60 HZ)starting powerapprox 40KW/42KWnormal power consumptionapprox 7.5KW/8KWwarming timeapprox 20 minstemp. setting rangeroom temp. -300ºCtemp. control methodPID Close Loop Control+SSR Drivingtemp. control precision±1ºCtemp. deviation on PCB±2ºC(by Jaguar Board Test Standard)nozzle platealuminilum alloy platedata storageprocess data and status storage(80GB)abnormal alramabnormal temp. (extra-high/extra-low temp. )board dropped alarmTower light: yellow-warming, green-normal, red-abnormalcooling systemcooling methodAir Oven: Forced Air. Nitrogen Oven: Water Chiller
