1.5-8.0mm Cable Copper Wire Twist Twisting Bunching Buncher Stranding 1250mm Bobbin Take up Machine

Kunshan Fuchuan Electrical and Mechanical Co., Ltd.
  • Driven Type：Electric
  • Condition：New
  • Certification：ISO, CE
  • Warranty：12 Months
  • Automatic Grade：Automatic
  • Mould Life：>1,000,000 Shots

Base Info

  • Model NO.：FC-1250B-1
  • Type：Double Stranding Machine
  • Transport Package：Standard Packing
  • Trademark：fuchuan
  • Origin：China
  • HS Code：8479811000
  • Production Capacity：500sets,Year

Description

Equipment modelsFC-1250BTwisting usageIt is applied to the twisting of above seven pcs of bare copper wires, tinned wires, silver jacketed wires ,enameled wires, and double twisting for core wires.Single wire dia(mm)φ0.5-φ2.14Stranding section area (mm²)10.0-50.0Core wire single wire diaφ3.0-φ8.0Core wire stranding outer diaφ6.0-φ16.0Pitch(mm)50-250(12zones)Direction of layOptional for right or leftTake up bobbin Outer dia*bore*outer widthφ1250*φ80*950Max rotating speed800(1600twist)Main motor power22KWInverter power22KWTension control methodTouch screen+ PLC+ magnetic powder clutch, it may ensure the constant tension from empty bobbin to full bobbinMagnetic powder clutch20kgfProtectionMachine will automatically brake when wire inside and outside is broken, the machine will automatically stop when the preset length is arrived.Brake modeElectromagnetic brakeTraversing methodRolling ring drive units, winding pitch and breadth are adjustableOperation modeTouch screen operationDimension(mm)4500L*2600W*2500H
