• Model NO.：HH-500
• Mould Life：>1,000,000 Shots
• Type：High-speed Stranding Machine
• Color：Optional
• Usage：Usage
• Technical Support：Overseas Support
• Function：Easy to Operate
• Packing：Negotiable
• Motor：Siemens
• Single Wire Diameter：1.5 - 5mm
• Max Stranded Diameter：35mm
• Central Pay-off Bobbin：500mm
• Main Motor Power：55kw,AC,380V,50Hz
• Stranding Pitch Range：65-875mm
• Transport Package：Plastic or Wooden
• Specification：500,630
• Trademark：HOOHA
• Origin：Guangdong
• Production Capacity：5 Sets,Month

Product Description

Components

Main Parts Brands

Product Advantage

Product Parameters

Features

1. Design the top hole of special machine processing frame to ensure the concentric degree of two holes so as to avoid the concentric problem affecting the tension
2. Optimized clamping structure, more stable pneumatic tension, more reliable clamping bearing
3. Ground shaft type frame stranding gear box gear tooth grinding processing to reduce noise
4. The design and optimization of the installation mechanism of the drive shaft of the frame stringing synchronous belt of the motor division ensures the machining accuracy and facilitates the tensioning adjustment of the synchronous belt
5. Newly added upper disc mechanism at the lower hydraulic side enriches the upper disc varieties
6. The newly added electric clamping mechanism enriches the clamping form

What can we provide

Address

Add: 3 rd Floor, Building D, No.38 Houhu Road, Humen Town, Dongguan City, Guangdong Province,China
