Full Automatic Cutting, Stripping, Twisting, Tinning and Crimping Machine (4 Wires Mode)

Jiangsu Bozhiwang Automation Equipment Co., Ltd.
  • Condition：New
  • Certification：ISO, CE
  • Warranty：12 Months
  • Automatic Grade：Automatic
  • Mode：Bw-4.0+Z
  • Outer Dimension：1280 X 680 X 1300mm

Base Info

  • Model NO.：BZW-4.0+Z
  • Power：AC 220V,50,60Hz
  • Cutting Length：8-350mm
  • Cutting Precision：1mm + Cutting Length X 0.1% Below
  • Stripping Length：0-7mm
  • Twisting Length：3-7mm
  • Tinning Length：0.5-7mm
  • Air Pressure：5-6 Kgf (Clean Air)
  • Precision：High Precision
  • Demoulding：Automatic
  • Heating System：Electric
  • Function：Abrasion Resistance
  • Mould Life：300,000-1,000,000 Shots
  • Customized：Customized
  • Transport Package：Wooden Case
  • Specification：CE
  • Trademark：Bozhiwang
  • Origin：Changzhou, China
  • HS Code：8537101990
  • Production Capacity：50000 PCS,Year

Description

Wire range (AWG20#--AWG32#) (Other size can be specially ordered)Applied wire PVC electronic wires, Mini TeflonCutting length 8mm-600mm (Other size can be specially ordered)Cutting precision ±( 0.1+0.05×L )mmStripping length 0-7mm (Other size can be specially ordered)Tinning length 0.5mm-7mmCrimping force 20KNPower 220V  50HZMotor 0.2KWAir supply 0.5 Mpa-0.7 Mpa,6m3/hWeight about 245 kgDimension 1280 x 680 x 1300 mmFunction Automatic wire cutting, single end stripping, double ends stripping, single end crimping, single end half stripping, single end twisting and single end tinningFull Automatic Cutting, Stripping, Twisting, Tinning and Crimping Machine (4 Wires Mode)
