• Model NO.：Newtopp
• Type：Triple Twisting Machine
• Range of Application：Wire and Cable
• Motor：Siemens
• Inverter：Japan-Yaskawa
• Transport Package：PE Film + Wooden Box
• Specification：CE SGS
• Trademark：NEWTOPP
• Origin：Guangdong, China
• HS Code：8479400000
• Production Capacity：100sets,Year

Basic Info.

Model NO. Newtopp Type Triple Twisting Machine Range of Application Wire and Cable Motor Siemens Inverter Japan-Yaskawa Transport Package PE Film + Wooden Box Specification CE SGS Trademark NEWTOPP Origin Guangdong, China HS Code 8479400000 Production Capacity 100sets/Year

Product Description

Wire and Cable Triple twisting machine for  CAT5E /CAT6/CAT7
 1.Application:
   Suitable for cat5, cat5e, cat6,cat7 Lan Cable pair twisting.
2.Machine Features:
   1) Triple pitchs design, 1.5 times speed to traditional double twisting machine when with 33% back twisting rate;
   2) Servo electonic pitch, setting by touch screen, PLC controller, accuracy within 2%;
    3) Active take-up, tension stable from empty to full bobbin.
3. Technical Parameters:

Model	XJ-500
Usage	Suitable for cat5, cat5e, cat6,cat7 Lan Cable pair twisting.
Rotate speed	Max.1800rpm
Suitable wire diameter	0.8-1.7mm
Twisted OD	1.5-3.5mm
Twisting pitch	50-50mm; electric pitch setting by touch screen
Pitch tolerance	+/_ 2%
Back-twist rate	0-100%
Tisting direction	S/Z
Tension display	Digital tension display
Pay-off and Take-up tension	Stable active rail tension
Motor power	Twist-bow motor 10HP, 1/2HP gear motor driving, with frequency inverter.

4. Brand of main parts:
1) Motor: Siemens; TECO
2) Driver: Yaskawa or inovance
3) Bearing:NSK, NACHI, ASCHI
4) Electric components: Omron
5. Safety performances:
1) Switch-off at overpressure
2) Disabling signal at under temperatures
3) Stop at over temperature
3) Motor power limit
4) Emergency stop
5) Monitoring of tolerances and alarms
6) Monitoring of sensors
6.Packaging & Shipping
1) Transparent PE film + Wooden box
2) Cardboard wrapping corner to protection, wire rope in fixed to sea ship
3) 20 Feet container for complete production Line equipment
 7.FAQ
1) Are you a manufacturer or trading company?
We are a manufacturer with more than 10 years manufacturing exprience in cable machinery, and we have 6000 spuare meters production workshop and office space.
2) How can we get to your factory to see the machines works?
Address: No286 Huai'de road, ,Humen Town, Dongguan City,Guangdong Province,China
We are near to Shenzhen Baoan International airport within 40 mins;
We are close to Guangzhou Baiyun Airport for 1.5-2 hours;
High speed rail from Guangzhou south station to Humen.
