High Quality Wire and Cable Extrusion Machine for Cable Sheath and Jacket

Dongguan Newtopp Electrical Machinery Co., Ltd.
  • Driven Type：Electric
  • Condition：New
  • Certification：CCC, PSE, UL, FDA, RoHS, ISO, CE, High Technology
  • Warranty：12 Months
  • Screw：Single-Screw
  • Range of Application：Wire and Cable

Base Info

  • Model NO.：xj-70
  • Motor：Siemens
  • Inverter：Japan-Yaskawa
  • Transport Package：PE Film + Wooden Box
  • Specification：CE SGS
  • Trademark：NEWTOPP
  • Origin：Guangdong, China
  • HS Code：8479400000
  • Production Capacity：100sets,Year

Description

Basic Info.

Model NO. xj-70 Motor Siemens Inverter Japan-Yaskawa Transport Package PE Film + Wooden Box Specification CE SGS Trademark NEWTOPP Origin Guangdong, China HS Code 8479400000 Production Capacity 100sets/Year

Product Description

Specifications

wire and cable extrusion machine
1).The diameter of the conductor:∅1.5-12mm
2).Finished diameter size: ∅3-24mm
3) PVC, LHNF,SR-PVC.PE.PP.PU


                                xj70 Jacket sheaft extrusion machine

 1.The usage of the machine:
   Used for power wire,computer wire,data wire and high frequency wire outside jacket insulation extrusion.
  2.Technical parameters:
   1).Wire specification :∅1.5-12mm
   2).Extrusion material: PVC,SR-PVC,LHNF,PE,PP,PU
   3).Screw parameters: L/D Ratio:26;1  Compression ratio:2.7~3.2   Screw material:38CrMoAlA,
   vacuum heating treament,Surface grinding polishing chromium plating
   4).Motor power:40HP
   5).Highest output:140KG/H
   6).Highest wire speed:400M/MIN
   7)Capstan power:5HP
   8) Pay-off spool specification: diameter∅ 500~1250mm
   9) Take-up spool specification: diameter∅400~630mm(Double-shafts)
   3. Composition of the equipment:

(A)∅1000mm dual-heads active pay off with magnetic powder 1set
(B)ø300mm bumper bracket1set
(C)∅70mm main extruder1set
(D)Centering adjustable crosshead1set
(F)2M Movable cooling water tank1set
(G) Laser diameter tester(Eectrl)1set
(H) 6M double layer cooling water tank1set
(I)10M high precision horizontal wire accumulator1set
(J)∅636mm dual-wheels capstan1set
(K) High frequency spark tester 1set
(L)∅800mm dual-axis take up1set
