• Model NO.：TB680LF
• PCB Width：250 X 300mm (Max)
• Temperature Control Segment：8 PCS
• Melting Time：80min
• Temperature Range：Room-Temperature -360 Degree
• Wave Height Adjust Range：5~10mm
• Conveyor Speed：0-1600mm,Min Adjustable
• Normal Working Power：10kw
• Dimension(L× W× H )(mm)：1800 × 700 × 655mm
• Conveyor Direction：R Tol or R to; L
• Transport Package：Wooden Case or Package as Your Request
• Specification：CE ISO
• Trademark：Torch
• Origin：Beijing
• HS Code：8514109000
• Production Capacity：10 PCS ,Month

Basic Info.

Model NO. TB680LF PCB Width 250 X 300mm (Max) Temperature Control Segment 8 PCS Melting Time 80min Temperature Range Room-Temperature -360 Degree Wave Height Adjust Range 5~10mm Conveyor Speed 0-1600mm/Min Adjustable Normal Working Power 10kw Dimension(L× W× H )(mm) 1800 × 700 × 655mm Conveyor Direction R Tol or R to; L Transport Package Wooden Case or Package as Your Request Specification CE ISO Trademark Torch Origin Beijing HS Code 8514109000 Production Capacity 10 PCS /Month

Product Description

                      Automatic Lead free smt/pcb welding machine

                                                                                                                     Model:TB680




TB680 has been developed by Torch, aiming at the practical status of the current soldering technology inland. It occupies the vacancy of the small automatic wave soldering inland. It adapts to the research and production in research center, war industry, middle- and small-sized corporation, small private corporation and other electronic production companies. The whole machine is a desk-type. The reasonable frame takes up little room. It has complete functions and it is cheap, however energy-saving with high efficiency. Besides TB680 is easy to operate and reliable in soldering so that it could be widely used, especially suitable for small and middle amount of production. TB680 could be the best device to replace the soldering iron by hand and the dip-soldering with tin pan. Compared with bigger ones, TB680consumes less energy. Quickly tin melting, easy to operate, simple to repair as well as maintain, automatic self-protection.  Electric control is designed assembled. The soldering tin temp, conveying speed, height of the

Specifications:
The max power consumption: 10KW
Solder pot capacityMax.240kgSn63Pb37200KgSn100%
PCB width (L×W)(mm): 250 X 300mm (max)
Temperature range:200~300
Preheating temperature : 100-190
Wave height adjust range: 5~10mm
Melting time 80min
Spray work mode:froth
Power supply380V,three phase four wires
Conveyor speed: 0.5-3mmin CTV
Dimension 1800 × 700 × 655mm
Weight 170Kg
