16 Heads LED SMD Placement Machine
Termway (Beijing) Precision Technology Co., Ltd.- After-sales Service：All Life
- Condition：New
- Speed：High Speed
- Precision：High Precision
- Certification：ISO, CE
- Warranty：12 Months
Base Info
- Model NO.：L16
- Automatic Grade：Automatic
- Type：High-speed Chip Mounter
- Mount Head：6 PCS
- Max Circuit Board Size：1200*350mm
- Max Moving Range：X Axis 1500mm, Y Axis410mm
- Max Moving Range of Z Axis：15mm
- Typical Mounting Speed：93000-140000cph
- Max Mount Speed：180000cph
- Mount Accuracy：+,-0.1mm
- Position Method：Machinery Position
- Component Available：0603 and Above SMD Component and LED, Sot, Sop
- Dimension：2600×680×1500mm
- Transport Package：Wooden Case
- Specification：2600× 680× 1500mm
- Trademark：TERMWAY
- Origin：China
- HS Code：8479896200
- Production Capacity：5 Sets Per Month
Description
3 Phase AC380V,4.0KVA
Visual Correction function and feeding function are equipped
1.When software runs, first need to run back to zero. If prompting zero back failure, then use the emergency button to clear the remove and re - return to zero.
2.The emergency stop button can stop machine and make it able to move each axis freely at this time.
3.Click the stop button can stop machine, click secondly can restore operation.
4. When editing LED board data, confirm the first post coordinate, then the rest coordinates will be automatically calculated.
5.Click the implementation button,then it will continue the fully automatic process.
6. Single step, cycle and a fully automatic mode of work can be selected in the model.
