• Model NO.：XJ500
• Mould Life：>1,000,000 Shots
• Customized：Customized
• Precision：High Precision
• Function：High Temperature Resistance
• Wire Specifiction：AWG32-AWG20
• Rotate Speed：Max2500rpm,Max20m,Min
• Pay-Offs Type：Slider Pendulum Rod+Hammer Tension Type
• Transport Package：PE Film+Wooden Box
• Specification：XJ-300
• Trademark：CE, CCC
• Origin：Dongguan City, Guangdong Province, China
• HS Code：8479400000
• Production Capacity：6 Sets,Month

Basic Info.

Model NO. XJ500 Mould Life >1,000,000 Shots Customized Customized Precision High Precision Function High Temperature Resistance Wire Specifiction AWG32-AWG20 Rotate Speed Max2500rpm/Max20m/Min Pay-Offs Type Slider Pendulum Rod+Hammer Tension Type Transport Package PE Film+Wooden Box Specification XJ-300 Trademark CE, CCC Origin Dongguan City, Guangdong Province, China HS Code 8479400000 Production Capacity 6 Sets/Month

Product Description

1). Purpose
Used for twisted wire and parallel wire single/double layers continuous centering tapping.

 2). Main specification
A. Max rotate speed: 2500RPM
B. Max wire speed: 35M/min
C. Input wire diameter: AWG32-AWG20
D. Tapping material: Aluminum foil tape,cotton paper tape,transparent tape,mica tape,teflon tape etc.
E. Machine color: As your requested
F. Operation direction: Right hand or Left hand (As requested)

3). Main parts
(A) ø400-500mm four-heads dynamic pay-off
(B) ø350mm centering tapping device
(C) Electrical control cabinet(touch screen)
(D) Automatic heating machine
(E) ø500mm Axis row-type take up machine

4). Brand of main accessories
A. Motor: Siemens
B. Frequency converter: Yaskawa(Japan) or Schneider (France)
C. Bearing: NSK,KOYO (Japan)
D. Electrical component: Schneider(France) or SHIHLIN(Taiwan)
E. PLC controller: Siemens or FATEK(Taiwan)
F. Touch screen: Tontek (Taiwan) or Pro-face(international brand)
5. Technical Parameters:

Model	XJ-500
Inlet wire specification	AWG32 - AWG20
Taping materical	aluminum foil tape, myra tape, cotton paper, transparent tape, mica tape, teflon tape etc.
Rotate speed	Max. 2000rpm / Max. 20m/min
Main power	Adjust the speed by 1HP motor driver, taping drum linkage with capstan motor
Taping tension	Taping tension automatic calculation tracking and keep constant from start to end,  no need any artificial adjustment.
Melting oven	Automatic flexible melting oven, OMRON temperature control, temperature tolerance:±1°C
Take -up tension	Take-up tension keep constant from start to end, no need any artificial adjustment.
Traversing type	Axis-row type take-up, no damage during the traversing process, traversing pitch and width can be adjusted.
Machine dimension	4250mm × 1500mm × 1900mm
Machine weight	2.5 T

6.FAQ
1) Are you a manufacturer or trading company?
We are a manufacturer with more than 10 years manufacturing exprience in cable machinery, and we have 6000 spuare meters production workshop and office space.
2) What is the advantages of your machine compared with competitors?
Our automatic control technology is in leading position in wire and cable equipment field.
Good cost performance, quality is steady.
The price is reasonable.
We combine the equipment and the wire&cable technology, offer you technology assistance
3) How can we get to your factory to see the machines works?
Address: No286 Huai'de road, ,Humen Town, Dongguan City,Guangdong Province,China
We are near to Shenzhen Baoan International airport within 40 mins;
We are close to Guangzhou Baiyun Airport for 1.5-2 hours;
High speed rail from Guangzhou south station to Humen.


Company Introduction(Why choose us):

1.Dongguan NewTopp Electrical Machinery Co.,ltd is a profeesional enterprise specializing in Wire&Cable equipment R&D, design and Manufacture, Located in Humen Town, Dongguan City. It has very convenient transportation because of the high-speed rail, welcome our customers come to visit our factory at any time.

2. We were founded in Year 2009 but we are famous in cable machine business line and enjoy the higher reputation, our competitors regards us as "dark horse" becuase our rapid development, we are full of passion and energy, also we keep innovating. We have 10  patented products.

3. There is almost 7000 square meter of our company, we have workers about 200. Also we have a system departments:  Such as Financial department, Engineering department, After-sales service department, Purchasing department, Production department, Sales department, Personnel department
Management department etc.
