• Model NO.：HC-608XZ
• Cutting Length：0.5-99999.99mm
• Stripping Length：200,130mm
• Cutting Range：10-120mm2
• Power：220V,2000W
• Display：English Interface or Chinese Interface LED Display
• Productivity：400-900PCS,H
• Feeding Way：Belt Feeding
• Transport Package：Wooden Box
• Specification：1500*1300*700MM
• Trademark：HeChang
• Origin：Changzhou City, China
• HS Code：8479899990
• Production Capacity：20,Month

Basic Info.

Model NO. HC-608XZ Cutting Length 0.5-99999.99mm Stripping Length 200/130mm Cutting Range 10-120mm2 Power 220V/2000W Display English Interface or Chinese Interface LED Display Productivity 400-900PCS/H Feeding Way Belt Feeding Transport Package Wooden Box Specification 1500*1300*700MM Trademark HeChang Origin Changzhou City, China HS Code 8479899990 Production Capacity 20/Month

Product Description

HC-608XZ Fully automatic multi-layer rotating cable cut and strip machine


   The fully programmable rotary incision unit allows easy processing of high precision coaxial and Multi-layer applications. The most prominent feature of the machine is rotating cutting function,  it can cut strip multilayer cable with clean cutting , shielding or braiding layer cutting cleanly . It can save large time for removing shielding braiding layer by hand .  The cut parameters can be individually optimised. layers and level of incision, and cut the weaving nets, saved manually cut shielded network time, means of stripping or straight strip can be arbitrary set, so as to achieve the effect of high efficiency is superio

high precision, thus greatly improving efficiency. You are assured maximum flexibility and even more efficient way of meeting your wire processing needs.belt feeding wire without leaving any traces, high precision, thus greatly improving efficiency.


Product details:



Feature:


  Broader processing range with a diversity of options and solutions
  Cutting to length and stripping of stranded and solid conductor wires and cables
  High precision,greatly improving efficiency.
  Intuitive, flexible and simple User-friendly english operation
  Extremely low maintenance

Techinical data:

HC-608XZ  Fully automatic multi-layer rotating cable cut and strip machine

Mode	HC-608XZ
dimension	L1500*W1300*H700mm
weight	500KG
Display	English / Chinese interface
power	220V/2000W
cutting length	10-100000mm
stripping length	front:1-200,end1-130MM Front end : 1-200mm   , rear end: 1-130mm
cable size	10-120mm2 , automatic regulation  , do not need to replace blades  (AWG7-AWG4/0)
Maximum stripping levels	1-8 layers
cable type	New energy cable , electric cables, coaxial cables, power cable , etc
Incise depth	0.01m
Max outer diameter	8-25mm
Drive supply	Servo drive
cut strip way	rotating cut and strip
Blades	2 pcs of imported High speed steel 2 pcs of Tungsten steel
Production rate	Approx 400- 900pcs/h (depending on conductor and programming)
feeding way	belt feeding , without leaving any traces no scratches

Certifications:

kindly reminder :

All our certifications are REAL ONE , NOT FAKE , NOT FAKE , NOT FAKE !!!!!

PLEASE CONTACT US TO SHOW YOU !!!

Exihibition:





welcome to contact with us for learn more automatic wire cutting stripping machine, terminals crimping machine, inkjet marking machine, coaxial cable stripping machine,

corrugated tube cutting machine, double end crimping machine ect .


Company Information:

Changzhou Hechang Machinery Co;Ltd is a Hi-tech professional manufacturer, Providing all-rounded solutions to wiring harness processing area for the customers from Electrical Appliances, Automotive, Industrial Control Automation,  instrument and apparatus.Medical ,Electric control cabinet , lighting and so on .
Our main products included Fully-automatic terminal crimping machine, Digital wire cutting & stripping machine, Terminal crimping machine, cable/wire printing inkjet marking machine ,Twisting Tinning machine , Seal insertion, Applicators for terminal crimping, Industrial robot and other special wiring harness processing electronic equipments.
Packaging:



Warranty:


We promise to give you one year warranty , long term technical support .

any problems duirng warranty , we promise to slove problem within 20hours.

if the machine can not working ,

We accept returns and refunds !


Our Service:

Please Attention :

1. factory direct price.

2. nice quality.

3.qucik shipping within 5 days

4.small order welcome

6.support 7 days refund money
