• Model NO.：HPC-2023
• Cutting Accuracy：<± (0.5+0.002*L)
• Wire Range：0.13-2.5mm² (AWG28-AWG14)
• Crimping Force：2ton
• Power：AC220V 50Hz 10A
• Air Source：>0.5MPa
• Air Consumption：140nl,Min
• Dimensions：870mm(W)× 1300mm(L)× 1450mm(H)
• Weight：500kg
• Precision：High Precision
• Demoulding：Automatic
• Heating System：Electric
• Function：Abrasion Resistance
• Mould Life：>1, 000, 000 shots
• Customized：Customized
• Transport Package：Wooden Case
• Specification：SGS
• Trademark：Hiprecise
• Origin：Xiamen, China
• HS Code：8537101990
• Production Capacity：30 Sets , Month

Basic Info.

Model NO. HPC-2023 Cutting Accuracy <± (0.5+0.002*L) Wire Range 0.13-2.5mm² (AWG28-AWG14) Crimping Force 2ton Power AC220V 50Hz 10A Air Source >0.5MPa Air Consumption 140nl/Min Dimensions 870mm(W)× 1300mm(L)× 1450mm(H) Weight 500kg Precision High Precision Demoulding Automatic Heating System Electric Function Abrasion Resistance Mould Life >1, 000, 000 shots Customized Customized Transport Package Wooden Case Specification SGS Trademark Hiprecise Origin Xiamen, China HS Code 8537101990 Production Capacity 30 Sets / Month

Product Description

Specifications

Automatic Terminal Crimping Machine
HPC-2023 wire cut and terminate Machine
Both ends crimping
Wire range: AWG28-14

Automatic Terminal Crimping Machine

 HPC-2023 wire cut and terminate Machine
Both ends crimping.
Applicable designed for automobile wiring harness processing.
Applicable Wire ranges: 0.13-2.5mm²(AWG28-AWG14)

Packaging & Delivery

Packaging Details:	Wooden case, 1500mm(L)*1360mm(W)*1890mm(H)
Delivery Detail:	30 working days after receiving your remittance

Feature
1. Applicable for home appliance and automobile harness processing.
2. Applicable Wire ranges: 0.08-2.5mm²(AWG28-AWG14)
3. Adopt Japan THK linear guide, Japan SUMITOMO precise servo reduction gears to ensure high accuracy and long life of the whole machine.
4. Adopt Japan SMC pneumatic elements, high reliability.
5. Touch man-machine graphics operation screen, visualized and concise.
6. Adopt Japan YOKOGAWA high-performance programmable controlling technology , Japan MITSUBISHI servo and Japan SANYO stepping controlling technology. The machine is stable, reliable and the processing accuracy is high.
7. Adopt the frequency conversion controls terminal crimping machine to accomplish power saving and low noise.

Model	HPC-2023
Cutting Length	40mm-99999mm
Stripping Length	Front end: 1.0mm-10.0mm; Rear end: 1.0mm-17.0mm
Cutting Accuracy	≤ ± (0.5+0.002*L) (Depending on equipment adjusting and wire materials)
Wire Range	0.13-2.5mm² (AWG28-AWG14)  MAXΦ 3.4mm
Crimping force	2 ton
Power	AC220V 50Hz  10A
Air Source	> 0.5Mpa
Air Consumption	140NL/min
Dimensions	870mm(W)× 1300mm(L)× 1450mm(H)
Weight	500Kg
