Generator Motor Three Working Station Stator Coil Winding Inserting Machine

Ningbo Nide Mechanical Equipment Co., Ltd.
  • Voltage：380V
  • Stator Diameter：0~150mm
  • Power Supply：380V 50,60Hz
  • Weight：3500kg
  • Color：Ral9010 or as Per Customer Requirement
  • After-Sales Service：Overseas Service Center Available

Base Info

  • Model NO.：Q3L1-75,130T
  • Automatic：Automatic
  • Certification：CE
  • Transport Package：Ply-Wooden Case
  • Specification：customized
  • Trademark：NIDE
  • Origin：China
  • HS Code：8479819000
  • Production Capacity：300PCS,Year

Description

Production name:Q3L1-75/130T three working station stator coil winding inserting machineStator stack length:30~120mmStator OD:≤150mmStator ID:50~120mmWire diameter:0.18~1.2mmAir source:0.6~0.8MpaPower supply:380V 50/60HZ 11KWWeight:3500KGDeminsion:2550mm(L)X 2230mm(W)X2300mm(H)
Customerized service1. Customized product design and manufacturing2. Customized tranning3.Technical suggestionsAfter-sales service1. Warranty Period: 12 month usually2. Overseas service center available

3. Engineers available to service overseas

Generator Motor Three Working Station Stator Coil Winding Inserting Machine
Generator Motor Three Working Station Stator Coil Winding Inserting Machine
Established in 2007, NIDE is a company devoted in the field of electric motors manufacturing, providing one-stop service for its customers.

NIDE has three main business divisions.
The first division is to provide different kinds of motor manufacturing machines, it is our Main business, including stand along machine, fully-auto complete line for armature and stator production, and the motor assembly line.
The second division is to supply the full range of motor components such as commutator, ball bearing, carbon brush, insulation paper, shaft, magnet, fan, motor cover, etc.
The third division is to provide technical support and consulting, project support and turn-key service for some motor manufacturing.
