• Model NO.：ND-LAW-5B4A
• Automatic：Automatic
• Certification：CE
• Transport Package：Ply-Wooden Case
• Specification：2000*1000*1800
• Trademark：NIDE
• Origin：China
• HS Code：8479811000
• Production Capacity：100 Sets,Year

Product name :automatic motor armature rotor winding machineWire diameter range:0.16~1.2 mmArmature diameter:20~60 mmStack length:10~70 mmShaft diameter:3~15 mmShaft length:less than 250mmArmature Slot:even slotTurn number:0~9999Commutator diameter:8~40 mmWinding speed:0~2500 rpmWinding motor power:1.5KW X 2Angle detecting speed:0~3000 rpmAngle detecting motor power:0.75KW X 1Air supply pressure:4~6 Kg/cm2Total power:4.0 KWVoltage:three phase AC 380V 50/60 HzDimension:2000(length)X1000(width)X1800(height)mmWeight:1250 Kg



Customerized service1. Customized product design and manufacturing2. Customized tranning3.Technical suggestionsAfter-sales service1. Warranty Period: 12 month usually2. Overseas service center available

3. Engineers available to service overseas

Established in 2007, NIDE is a company devoted in the field of electric motors manufacturing, providing one-stop service for its customers.

NIDE has three main business divisions.
The first division is to provide different kinds of motor manufacturing machines, it is our Main business, including stand along machine, fully-auto complete line for armature and stator production, and the motor assembly line.
The second division is to supply the full range of motor components such as commutator, ball bearing, carbon brush, insulation paper, shaft, magnet, fan, motor cover, etc.
The third division is to provide technical support and consulting, project support and turn-key service for some motor manufacturing.
