• Model NO.：XJ-4+4+8,6+6+6
• Type：To Back Stranding Machine
• Machine Name：Planetary Strander Line
• Application Wire Spec.：0.5-2.0mm
• Twisting Od：2-10mm,2-15mm
• Twisting Pitch：20-300mm,20-500mm
• Rotate Speed：Max.200 Rpm
• Main Power：10HP,15HP
• Back-Twist Rate：0-100% Stepless Adjustable
• Traversing Type：Servo Traversing
• Precision：High Precision
• Demoulding：Automatic
• Heating System：Electric
• Function：High Temperature Resistance
• Customized：Customized
• Transport Package：PE Film + Wooden Pallet
• Specification：CE SGS
• Trademark：NEWTOPP
• Origin：Dongguan, China
• HS Code：8479400000
• Production Capacity：6 Sets,Month

Suitable for USB3.1, QSFP and so on high standard telecommunication wire&cable stranding/twisting.Applicable wire dia.0.5mm - 2.0mmTwisting OD(max.)Φ2 - 10mmΦ2 - 15mmTwisting pitch20 - 300mm20 - 500mmRotate speed(max.)200 RPM200 RPMMain power10HP15HPPay-off type4+4 heads equal proportion arrangement6+6 heads qual proportion arrangementTaping typeHighspeed centering taping, automatic tension tracking, taping tension can be constant from start
 to end, no need any manual regulation.      Pay-off tension Magnetic power tension, automatic tracking by meter counter, taping tension can be constant
from start to end, no need any manual regulation.      Traversing typeServo traversing, no damage during the traversing process, traversing space and pitch can be
 adjusted according to the wire specification.
4. Brand of main parts:
1) Motor: Siemens
2) Driver: Yaskawa or inovance
3) Bearing:NSK, NACHI, ASCHI
4) Electric components: Omron

5. Safety performances:
1) Switch-off at overpressure
2) Disabling signal at under temperatures
3) Stop at over temperature
3) Motor power limit
4) Emergency stop
5) Monitoring of tolerances and alarms
6) Monitoring of sensors

6. About us
Dongguan NewTopp Electrical Machinery Co.,Ltd is a high-tech enterprise which specializes in developing and manufacturing wire and cable machines, and our main products includes all kind of extrusion production line, single twisting machine, double twisting machine, cantilever stranding machine, cage-type twisting machine, planetary cabling machine, triple-core stranding with back-twist and taping, and single layer/double layer taping machine etc. and our products have passed CE certification and SGS audited , and we also have passed ISO9001:2008 since 2010.

7.FAQ
1) Are you a manufacturer or trading company?
    We are a manufacturer with more than 10 years manufacturing exprience in cable machinery, and we have          6000 spuare meters production workshop and office space.
2) How can we get to your factory to see the machines works?
    Address: No286 Huai'de road, ,Humen Town, Dongguan City,Guangdong Province,China
    We are near to Shenzhen Baoan International airport within 40 mins;
    We are close to Guangzhou Baiyun Airport for 1.5-2 hours;
    High speed rail from Guangzhou south station to Humen station.
