Wisdom Tt-H12c Toroidal Coil Winding Machine Replace Ruff, Jovil, Gorman

Wisdom Import & Export (Shanghai) Co., Ltd.
  • Warranty：24 Months
  • Coil O.D.：50-254mm
  • Min.Fin. I.D.：42mm
  • Max. Height：152mm
  • Speed：200rpm
  • Wire Size：0.6-2.5mm

Base Info

  • Model NO.：TT-H12C
  • Shuttle Diameter：266mm
  • Net Weight：95kg
  • Winding Motor：0.75kw AC Motor, Variable Frequency Drive
  • Dimensions：950mm X850 mm X900 mm
  • Power Source：220V ±10%; 50 , 60 Hz
  • Precision：High Precision
  • Demoulding：Pull Core
  • Heating System：No
  • Function：High
  • Mould Life：>1, 000, 000 shots
  • Automatic Grade：Semiautomatic
  • Condition：New
  • Customized：Non-Customized
  • Certification：CE, ISO
  • Transport Package：Plywood Box, According Custormer′s Requirement
  • Specification：high quality
  • Trademark：WISDOM
  • Origin：China
  • HS Code：8479811000
  • Production Capacity：500 Sets Per Month

Description



Machine Type
TT-H12C
WIRE SIZE
0.6-2.5mm
SHUTTLE DIAMETER
266mm
MIN.FIN. I.D.
42mm
SPEED
200RPM
COIL O.D.
50-254mm
MAX. HEIGHT
152mm
WINDING MOTOR

0.75KW AC motor, variable frequency drive

POWER SOURCE
220V ±10%; 50 / 60 Hz
Net weight
95KGDimensions
950mm X850 mm X900 mm
