• Model NO.：XJ300
• Mould Life：>1,000,000 Shots
• Customized：Customized
• Precision：High Precision
• Function：High Temperature Resistance
• Wire Specifiction：AWG28-AWG38
• Transport Package：PE Film+Wooden Box
• Specification：XJ-300
• Trademark：CE, CCC
• Origin：Dongguan City, Guangdong Province, China
• HS Code：8479400000
• Production Capacity：6 Sets,Month

Basic Info.

Model NO. XJ300 Mould Life >1,000,000 Shots Customized Customized Precision High Precision Function High Temperature Resistance Wire Specifiction AWG28-AWG38 Transport Package PE Film+Wooden Box Specification XJ-300 Trademark CE, CCC Origin Dongguan City, Guangdong Province, China HS Code 8479400000 Production Capacity 6 Sets/Month

Product Description

1.Application:
Used in single coaxial wire and similar wire winding and taping.
2.Machine Features:
It's used in USB3.1 ( coaxial structure) series coaxial winding taping process, used to coaxial wire back-twist, high speed winding, double layer taping etc. finished at a time.
3. Technical Parameters:

Model	XJ-300 Horizontal micro-fine winding and taping machine
Usage	Used in single coaxial wire and similar wire winding and taping.
Core wire spec.	AWG28 - AWG38
Taping material	Aluminum foil tape, myra tape, transparent tape, mica tape etc.
Rotate speed	Max.2000rpm
Machine power	Whole set servo motor with servo controller, taping plate is linkage with capstan motor.
Taping tension	Automatic calculation and tracking, and keep constant from start to end, no need any  manual adjustment.
Heating device	Auto-flexible type, OMRON temperature control, temperature controlled within ±1°C
Take-up tension	Take-up tension keep constant from start to end, no need any manual adjustment.
Take-up type	Axis-row type take-up, no damage during the traversing process, traversing pitch and width can be adjusted.
Pay-off  type	Back-twist pay-off, back-twist rate 0-100%, Stepless adjustment
Winding spindle	56 Heads( according to practical situation)
Winding pay-off tension	Friction type tension control
Pay-off /Take-up bobbin size	Pay-off 200mm; Take-up 300mm

4. Brand of main parts:
1) Motor: Siemens
2) Driver: Yaskawa or inovance
3) Bearing:NSK, NACHI, ASCHI
4) Electric components: Omron

5.FAQ
1) Are you a manufacturer or trading company?
We are a manufacturer with more than 10 years manufacturing exprience in cable machinery, and we have 6000 spuare meters production workshop and office space.
2) What is the advantages of your machine compared with competitors?
Our automatic control technology is in leading position in wire and cable equipment field.
Good cost performance, quality is steady.
The price is reasonable.
We combine the equipment and the wire&cable technology, offer you technology assistance
3) How can we get to your factory to see the machines works?
Address: No286 Huai'de road, ,Humen Town, Dongguan City,Guangdong Province,China
We are near to Shenzhen Baoan International airport within 40 mins;
We are close to Guangzhou Baiyun Airport for 1.5-2 hours;
High speed rail from Guangzhou south station to Humen.
