Torch Small SMT Mini Desktop Visual Chip Mounter Tp210+
Termway (Beijing) Precision Technology Co., Ltd.- Condition：New
- Precision：High Precision
- Certification：ISO, CE
- Warranty：6 Months
- Automatic Grade：Automatic
- Max PCB Size：300*200mm
Base Info
- Model NO.：TP210+
- Accuracy：± 0.01mm
- Max Speed：2600-3000 Cph
- Repeat Accuracy：0.05mm
- Positioning：Visional Position+ Machinery Position
- Component Available：0603, 0805, 1206 etc and Sop, Soic
- Program Way：Software Program Input
- Automatic Feeder：8mm, 12mm, 16mm, 24mm Feeder Can Choose
- Feeder Num：Can Set 50 PCS of 8mm Feeder
- IC Plate Num：More Than 1
- Demoulding：Automatic
- Heating System：Electric
- Customized：Customized
- Function：High Precisio Mounting
- Transport Package：Wooden Package, About 180kg
- Specification：Middle Speed Machine
- Trademark：TERMWAY
- Origin：Beijing, China
- HS Code：8479896200
- Production Capacity：300 Sets,Year
Description
Type
TP210+
Max PCB size
300x200mm
max moving range
400×460mm
max moving range of Z axes
10mm
Typical pick&place speed
2600-3000cph
max pick&place accuracy
±0.014mm
repeat accuracy
±0.05mm
Positioning
Visional Position+ Machinery Position
Component Available
0603, 0805,1206 etc and SOP, SOIC (size under 15*15mm, PIN foot less than 24)
Program way
Software program input
Driving mode
use industrial Synchronous belt to drive
Automatic Feeder
8mm,12mm,16mm,24mm feeder can choose
Feeder Num
Can set 50 pcs of 8mm feeder
IC Plate Num
More than 1
Operating system
WINDOWS XP
compressed air
80psi(0.5Mpa)
Power supply
220V,50Hz
Weight
95kg
Dimension
980×1000×590mm
Summary
1. "Automatic Pick and Place Machine TP210+" Component available for below 20mm SOP columnar diode, triode, SOT, SOP, IC chips and and 0603 component ( except of 5m Aluminum electrolysis electric capacitor ) ect
2. Intelligent electrical feeder 3. Program and mounting technology for multi -panels 4. Off-line program function 5. Program control 6. Visional program 7. Powerful data import function, any formats of PCB file can be imported. a new program can be finished in 10 minutes 8. Stably pick and place SMD 0402 9. Security cover for protection of operator to dustproof 10. High precision linear guiderail 11. Configurate 5 kinds of nozzle, software reminds of "nozzle changing".
