SMT Pick and Place Machine I-Pulse Chip Mounter -M2-Plus

Qinyi Electronics Co., Ltd.
  • Condition：Used
  • Speed：High Speed
  • Precision：Precision
  • Certification：ISO, CE
  • Warranty：6 Months
  • Automatic Grade：Automatic

Base Info

  • Model NO.：M2-Plus
  • Type：High-speed Chip Mounter
  • Part No.：M1 Plus
  • Lead Time：1-2 Weeks After Payment
  • Shipping Ways：DHL, FedEx, TNT, UPS, EMS, by Sea, by Air
  • Transport Package：Normal Packing
  • Trademark：I-PUSE
  • Origin：USA
  • Production Capacity：50 PCS , Year

Description

I-Pulse- M2 Plus SpecificationBoard sizeL50xW50mm - L460 xW410mmBoard thickness0.5mm-2.0mmFlow directionLeft to rightConveyor speedMax. 420mm/sec, speed variable, soft stop fuctionPlacement speed A (NB1)0.13 sec/CHIP, 0.38 sec/TSOP32Placement speed B (NB2)0.54 sec/QFP100 (when using the optional fixed camera FCO5)Placement accuracy A (u+3o)CHIP +0.05mmPlacement accuracy B (u+30c)QFP +0.03mm (when using the optional fixed camera FCO3)Placement angle+180', resolution 0.015Z-axis control6-head independent servo motors, resolution 0.006mmComponent height15mm (Preplaced components max. 10.5mm)Components applicable0603 (option) - SOP, PLCC, QFP, BGA, CSP, connector, and odd-form componentsComponent carriers8-56mm tape, stick, trayDrawback checkVacuum check and vision checkMulti language displayJapanese, Chinese, Korean, and EnglishBoard locating methodBoard edge or tooling hole (option), front referenceComponent types120 types (8mm tape conversion)Board transfer height900+20mmDimensions, weightL1,750XD1,530XH1, 510mm, approx. 1,950KgPower, consumption, capacity3phase 200V (Option: 208, 220, 240, 380, 400, 415, 440V) +10% 50/60Hz, 4.0KVA, 6.0KVAAir and consumption0.5MPa, 692/min A.N.R.
Download Details
  • Model M2 is a super mid-range machine that integrates the speed of a chip shooter and the multi-function of an IC mounter in one unit.
  • Further enhanced the standard mid-range model M1 / M1plus, the M2 has achieved great improvement in its speed, accuracy, and the function
  • 7 High specifications support speed
