• Model NO.：XJ1200mm,2700mm
• Motor：Siemens
• Transport Package：PE Film + Wooden Box
• Trademark：Newtopp
• Origin：Dongguan, China
• HS Code：8479400000
• Production Capacity：20 Sets,Month

Basic Info.

Model NO. XJ1200mm/2700mm Motor Siemens Transport Package PE Film + Wooden Box Trademark Newtopp Origin Dongguan, China HS Code 8479400000 Production Capacity 20 Sets/Month

Product Description

1.Machine Feature:
Application:Suitable for aviation & aerospace cable,high-demand automotive cable and cable which external
signal base station etc,with excellent chemical stability,outstanding surface non-sticky,good lubrication and
resistance to atmospheric aging,and can be work at 250ºC and -60ºC low temperature for long time as well.
Model:Optimizing 1200mm vertical cold extruding line,2700mm horizontal cold extruding line
Equipment composition:
Mixer,premolding machine,cold extruding machine,traction machine(volatile box),sintering furnace,
take-up and traversing machine and outer diameter tester,main control cabinet and operating table etc.

2.Technical parameters:

Model	1200mm PTFE cold extrusion line	2700mm PTFE cold extrusion line
Structure type	Vertical	Horizontal
Cold-extruded motor	4.5KW Servo motor+5KW AC motor	50T double hydraulic cylinder
Cold-extruded force(Max)	35T	100T
Capstan power	400W	2000W
Pay-off power	750W	2000W
take-up power	750W	5500W
Volatile-tank power	8KW	15KW
Sintering furnace power	45KW	45KW
Temperature range	0-500ºC control accuracy +/-1ºC	0-500ºC control accuracy +/-1ºC
Design line speed	0-50(40) m/min	0-80(40) m/min
Plane size of machines	9280mm*2500mm(subject to the actual product)	19000mm*2500mm(subject to the actual product)
Machines height	13500mm(subject to the actual product)	13500mm(subject to the actual product)

3.Brand of main parts:
1) Motor: Siemens
2) Driver: Yaskawa or inovance
3) Bearing:NSK, NACHI, ASCHI
4) Electric components: Imported famous brands.

4.Packaging & Shipping:


5.Trade exhibition:








6.Our Services
Pre-sale Services:
1) Spot investigation and professional guiding suggestions;
2) Equipment configuration, model selection reference and technical consultation;
3) Onestop service for investment equipment,product developing, new materials researching and personnel training.
Sale Services:
1) Invite customers to inspect and take trials of finished machines;
2) Provide the training of the maintenance knowledge;
3) Improve the design to the operator's requirements.
After-sale Services:
1) Regular maintenance and product tracking service;
2) Cost price for required parts in lifelong period;
3) Provide quality and efficient after-sale service life long time.

7.Company certification
