Torch Germany Economical IGBT Mems Laser Diode Packaged Reflow Vacuum Oven RS220
Termway (Beijing) Precision Technology Co., Ltd.- After-sales Service：1 Year
- Condition：New
- Certification：ISO, CE
- Warranty：24 Months
- Automatic Grade：Automatic
- Installation：Vertical
Base Info
- Model NO.：RS110
- Furnace Height：40mm(Other Hights Is Optional)
- Temperature Range：up to 400
- Connector：Serial 485 Network , USB
- Control Way：40 Segments Temperature Control + Vacuum Pressure
- Temperature Curve：Can Store Several Curves Temperature of 40 Segment
- Transport Package：Plywood with Foam Inside
- Specification：450*450*1300mm
- Trademark：torch
- Origin：China
- Production Capacity：10 PCS,Month
Description
40mm(other Hights is optional) Temperature Range Up to 400 Connector Serial 485 network / USB Control Way 40 segments Temperature control + Vacuum Pressure Control Temperature curve can store several curves Temperature of 40 segments Voltage 220V 25A 220V 28A 220V 36A Rated Power 9KW 11KW 15KW Actual Power 6KW(Don't choose a vacuum pump) 8KW(configurate molecular pump) 11KW(Don't choose a vacuum pump) 8KW(configurate molecular pump) 10KW(configurate molecular pump 13KW(configurate molecular pump) Dismension 450*450*1300mm 450*450*1300mm 500*450*1300mm Wight 210KG 240KG 270KG The maximum heating rate 120/min 120/min 120/min The maximum cooling rate 80k/min 80k/min 80k/min Cooling Way
Air-cooled / water-cooled Air-cooled / water-cooled
Our factory
| Air-Cooled / Water-Cooled |
Our factory
