Horizontal Single Side Stator Coil Lacing Machine for High Winding Overhang Big Electric Motor

Ningbo Nide Mechanical Equipment Co., Ltd.
  • Stator I.D：90-250mm
  • Stator Stack Height：125~300mm
  • Stator O.D：200~320mm
  • Over-Hang Height：20~65mm
  • Slot Number：8~48 Slots
  • Power Source：AC 220V±10% 50,60Hz

Base Info

  • Model NO.：BXIW1-300-320N
  • Total Power：4.5kw
  • Weight：800kg
  • Dimension：1500*1200*1500mm
  • Transport Package：1 Ply-Wooden Case
  • Specification：800KG
  • Trademark：NIDE
  • Origin：China
  • HS Code：8479899990
  • Production Capacity：100 Sets,Year

Description

Power: 4.5KWWeight:800KGDimension:1500*1200*1500mm


Customerized service1. Customized product design and manufacturing2. Customized tranning3.Technical suggestionsAfter-sales service1. Warranty Period: 12 month usually2. Overseas service center available

3. Engineers available to service overseas

Horizontal Single Side Stator Coil Lacing Machine for High Winding Overhang Big Electric Motor
Horizontal Single Side Stator Coil Lacing Machine for High Winding Overhang Big Electric Motor
Established in 2007, NIDE is a company devoted in the field of electric motors manufacturing, providing one-stop service for its customers.

NIDE has three main business divisions.
The first division is to provide different kinds of motor manufacturing machines, it is our Main business, including stand along machine, fully-auto complete line for armature and stator production, and the motor assembly line.
The second division is to supply the full range of motor components such as commutator, ball bearing, carbon brush, insulation paper, shaft, magnet, fan, motor cover, etc.
The third division is to provide technical support and consulting, project support and turn-key service for some motor manufacturing.
