Torch IGBT SMT Small Desktop Leadfree Reflow Oven T200c
Termway (Beijing) Precision Technology Co., Ltd.- Condition：New
- Certification：CCC, ISO, CE
- Warranty：24 Months
- Automatic Grade：Semiautomatic
- Installation：Desktop
- Temperature Control Segment：40 Segment .The Segment Can Be Set in Computer Acc
Base Info
- Model NO.：T200C
- Temperature-Zone Numbers：Single-Zone and Multi-Segment
- Temperature Control System：PC Control System ,SSR Non-Contact Output.
- Warm-up Time：3min
- Heating Supply：Infrared Ray + Hot Air Convection
- Effective Working Table Area：360mm * 230mm (Less Than A4)
- Welding Time：3min±1min
- Temperature Curve：It Can Be Set ,Adjusted and Tested According to Th
- Cooling System：Transverse Flow Equal Cooling
- Weight：39kg
- Transport Package：Wooden Case
- Specification：CE
- Trademark：Torch
- Origin：Beijing
- HS Code：8514109000
Description
Item
Parameter
Temperature control segment
40 segment .The segment can be set in computer according to the actual requirement.
Temperature-zone numbers
Single-zone and multi-segment
Temperature control system
PC control system ,SSR non-contact output.
Temperature accuracy
±2ºC
Warm-up time
3min
Temperature range
Room-temperature -360 ºC
Heating supply
Infrared ray + Hot air convection
Effective working table area
360mm * 230mm (less than A4)
Welding time
3min±1min
Temperature curve
It can be set ,adjusted and tested according to the actual requirement .
Cooling system
Transverse flow equal cooling
Rated voltage
AC single-phase ,220V;50Hz
Rated power
3.8KW
Mean power
1.6kw
Weight
39kg
Dimension
Length*width*height 700*460*310mm
