2 Poles Universal Motor Stator Automatic Coil Winding Machine

Ningbo Nide Mechanical Equipment Co., Ltd.
  • Voltage：AC380V, 50,60Hz
  • Warranty：1 Year
  • After-sales Service：Overseas Service Center Available
  • Stator O.D：50~130mm
  • Wire Diameter：0.5-1.3mm
  • Stator Stack Length：10-70mm

Base Info

  • Model NO.：ND-SW-2A
  • Slot Number：2 Poles
  • Air Pressure：0.4~0.7MPa
  • Weight：1200kgs
  • Dimension：1500*2100*1650mm
  • Machine Color：Ral9010 or as Per Customer Requirement
  • Automatic：Automatic
  • Certification：CE
  • Transport Package：Suiitable for Sea Transprotation
  • Specification：1500*2100*1650mm
  • Trademark：NIDE
  • Origin：China
  • HS Code：8479811000
  • Production Capacity：100 Sets,Year

Description

Product name:Automatic 2 poles electric motor stator coil winding machineStator O.D:50~130mmStator I.D:20~60mmWire diameter:0.5~1.3mmStator stack length:10~45mmm(standard);30~70mm(lengthen)Slot number:2 polesWorking stations:2Air pressure:0.4~0.7MPaLubrication mode:Continuous lubrication oiling machineVoltage:AC380V,50/60Hz,4.5KWWeight:1200KgsDimension:1500*2100*1650mm

(2)Application:
This motor stator automatic coil winding machine is suitable for two poles stator coil winding,such as universal motor,series motor.


(3) Machine Function and characteristic:
1. The motor winding machine has two working stations.
2.The maximum winding speed is up to 450 rpm (according to the wire diameter).
3.Cast iron or steel frame can absorb the shock. Accuracy is stable.
4. All the actions are fully automatic (including loading and unloading). The winding could be more stable and efficient.
5. Fixtures are in cycle operation automatically. It is benefit for the on-line operation.
6. The cutting part structure is in compact. Wire clamping and cutting is finished at the same time.
7. Travel and swing angle is adjusted within 150-220 mm (mechanical adjustment) .It could adapt to different requirement of different stator models.
8. Easily to change the fixture for different types of stators.
9.Permanent magnet tensioning device enables the tension adjustment.

2 Poles Universal Motor Stator Automatic Coil Winding Machine

With good service, unique philosophy, professional team and reliable quality, we win the worldwide customers' confidence gradually. We directly and indirectly supply our products to more than 50 countries .

Customerized service1. Customized product design and manufacturing2. Customized tranning3.Technical suggestionsAfter-sales service1. Warranty Period: 12 month usually2. Overseas service center available

3. Engineers available to service overseas

2 Poles Universal Motor Stator Automatic Coil Winding Machine
Established in 2007, NIDE is a company devoted in the field of electric motors manufacturing, providing one-stop service for its customers.

NIDE has three main business divisions.
The first division is to provide different kinds of motor manufacturing machines, it is our Main business, including stand along machine, fully-auto complete line for armature and stator production, and the motor assembly line.
The second division is to supply the full range of motor components such as commutator, ball bearing, carbon brush, insulation paper, shaft, magnet, fan, motor cover, etc.
The third division is to provide technical support and consulting, project support and turn-key service for some motor manufacturing.
