• Model NO.：A600
• Transport Package：Wooden Box
• Specification：CE ,UL
• Trademark：ETA
• Origin：China
• HS Code：8515190000
• Production Capacity：100 Set,Month

GENERALOutside dimension5140x1300x1580mmStandard colorComputer greyWeight1800kgNumber of heating zonesUp8/bottm8Lengthof heating zones2900mmNumber of cooling zones2(built-in)Exhaust volume10M3/minx2 ExhaustsStandard feature of control systemElectric supply required3phase, 380V 50/60Hz Electric power required64KWPower for warm up32KWPower consumption10KWHeating patternUp& Bottom Hot airWarming timeApprox. 30minuteTemp. setting rangeRoom temp__300degreeControl systemPLC+ ComputerTemperature control methodPID close loop control +SSR drivingTemperature control precision± 1.0degreeTemperature deviation on PCB± 1.0degreeData storageProcess data and status storage (80GB)Abnormal alarmAbnormal temperature(extra-high/extra-low temp)Board dropped alarmTower light: yellow warming: Green-normal: Red-abnormalStandard features of conveyor systemMax. width of PCBMax: 450mm(Standard)Rail Number1 Lane(standard)Components clearanceTop/bottom clearance of PCB is 25mmConveyor heightLight → right(option: R→ L)PCB transmission agentAir-reflow=chain +mesh (Standard)Conveyor height900/± 20mmConveyor speed range300~2000mm/min  Standard features of conveyor systemMax. width of PCBMax: 450mm(Standard)Rail Number1 Lane(standard)Components clearanceTop/bottom clearance of PCB is 25mmConveyor heightLight → right(option: R→ L)PCB transmission agentAir-reflow=chain +mesh (Standard)Conveyor height900/± 20mmConveyor speed range300~2000mm/min
For SMT factory setup,we can do for you:
1. We provide fulL SMT solution for you
2. We provide core technology with our equipments
3. We provide the most professional tech service
4. We have wealthy experience on SMT factory setup
5. We can solve any question about SMT



ETA is the leading SMT factory solution provider in China,offering professional SMT factory building
advice and service.We have 20 year experience about SMT factories,offering full solutions for global
clients with our great advantaged sources.Our core technology team members are well experienced in
SMT field, learning experience from top international chip mounters meanwhile increasing independent
research and development. Currently ETA SMT equipment is representative of high quality , has
maintained absolute leading technology in the industry.
Over the years the company has been committed to improving technology, quality and perfect service.
ETA makes a positive contribution to international standard,the annual total capacity of 1200 sets,
passed the ISO9001: 2000, ISO14000, CE, UL, RoHS and other certifications. Full implementation of
the IPD process, reliable design and testing throughout the entire product life cycle.ETA's
continued investment in research and development and great contribution has been unanimously
recognized in the field. By the end of 2012, ETA has declared more than 30 patents and software
copyrights (including four invention patents), and actively involved in a number of national and
industry standards. ETA provides more advanced products and fast technical support for global
customers, at home and abroad.
