460 Vacuum Loader SMT Line PCB Machine

Winson Automation Equipment (HuiZhou) Co., Ltd.
  • Condition：New
  • Speed：High Speed
  • Precision：High Precision
  • Certification：CE
  • Warranty：12 Months
  • Automatic Grade：Automatic

Base Info

  • Model NO.：VH-460E-ST
  • Type：High-speed Chip Mounter
  • Material of Stents：Sheet Metal
  • Lead Time：20~25 Days
  • Direction：L to R , R to L
  • Belt：Round,Flat
  • Customized：Customized
  • Application：SMT
  • PCB Size：50*50~535*460mm
  • Transport Package：Wooden Case
  • Specification：800*835*1250mm
  • Trademark：Above Auto
  • Origin：Mainland China
  • HS Code：8428330000
  • Production Capacity：5000 Sets,Year

Description

Basic Info.

Model NO. VH-460E-ST Type High-speed Chip Mounter Material of Stents Sheet Metal Lead Time 20~25 Days Direction L to R / R to L Belt Round/Flat Customized Customized Application SMT PCB Size 50*50~535*460mm Transport Package Wooden Case Specification 800*835*1250mm Trademark Above Auto Origin Mainland China HS Code 8428330000 Production Capacity 5000 Sets/Year

Product Description


Since 1996,
Winson Electronic Manufacturing Equipment Limited. mainly produce SMT automation equipment,include conveyors/loader/unloader/inverter/buffer/gate conveyor etc series.Currently,we are dedicated in automatic attach machines developing,to help PCB industry,precison electronic adhesive products factories to solve the FPC reinforcing steel sheet,FPC gum,lens gum and PCB label attachment problems,avoid inaccurate attach and slow speed,high labor cost.
WEC brand attach machines series are self-developed in hardware and software.Now,FPC reinforcing steel sheet attach machine,MYLAR attach machine,label attach machines are in mass production,inline or off line are optional,provide perfect solution for automatic SMT line.

Production Workshop




Description:
PLC control system.
Suction and pass through function.
Flexible suction cup design,position adjustable.
Sucking stability imoroved by using single vacuum generator system.
Motor drive the screw to adjust the width of PCB.
Use AirTAC cylinder.
Standard SMEMA.

Specifications:
Power Supply:AC220V/50-60HZ
Air Supply:5kgf/cm²
PCB Size:535*50~460mm
PCB direction:left to right or right to left
Transport Height:900±20mm
Transmission Speed:10s/pcs
Storage Height:200
Track Fixed Side:front side fixed(back side fixed)
Main Motor Power:80W
Machine Size L*W*H:800*835*1250mm
Weight:190KGS
