• Model NO.：ND-SW01B
• Machine Color：Ral9010 or as Per Customer Requirement
• Winding Method：Needle Winding
• Automatic：Automatic
• Certification：CE
• Transport Package：Wooden Case
• Specification：ISO9001
• Trademark：NIDE
• Origin：China
• HS Code：8479811000
• Production Capacity：100 Sets,Year

Product name:

BLDC water motor stator coil winding machine

BLDC Stator ID:

45-180mm

BLDC Stator OD:

60-210mm

Wire dia.:

0.15-1.2 mm

Stack length:

5-160mm

Coil Winding Method:

Needle winding

Needle Winding speed:

50-400 r/min

Needle working stations .:

one

Pole No.:

4

Air pressure:

0.5MPa~0.7 MPa

Voltage:

380V/50HZ three phase four wires

Power:

10 KW

Dimension:

1200L*750W*1900H

Weight:

About 300kg

Customerized service1. Customized product design and manufacturing2. Customized tranning3.Technical suggestionsAfter-sales service1. Warranty Period: 12 month usually2. Overseas service center available

3. Engineers available to service overseas

Established in 2007, NIDE is a company devoted in the field of electric motors manufacturing, providing one-stop service for its customers.

NIDE has three main business divisions.
The first division is to provide different kinds of motor manufacturing machines, it is our Main business, including stand along machine, fully-auto complete line for armature and stator production, and the motor assembly line.
The second division is to supply the full range of motor components such as commutator, ball bearing, carbon brush, insulation paper, shaft, magnet, fan, motor cover, etc.
The third division is to provide technical support and consulting, project support and turn-key service for some motor manufacturing.
