Economic Type Automatic Stator Winding Final Forming Coil Shaping Machine

Ningbo Nide Mechanical Equipment Co., Ltd.
  • Voltage：380V,50Hz
  • Stator I.D：15~150mm
  • Max Stator O.D：200mm
  • Power：2.5kw
  • Weight：500kg
  • Dimension：1300X630X2000mm

Base Info

  • Model NO.：NI-HSX-4C
  • After-Sales Service：Overseas Service Center Available
  • Machine Color：Ral9010 or as Per Customer Requirement
  • Automatic：Automatic
  • Transport Package：1 Ply-Wooden Case
  • Specification：ISO
  • Trademark：NIDE
  • Origin：China
  • HS Code：8479819000
  • Production Capacity：100 Sets,Year

Description

Stack height15-150mmMax stator OD200mmStator ID range≥30mmDisplacement of cylinder20FPower supply380V/50HZPower2.5KWDimension1300x630x2000mmWeight500KG

Application
It is suitable for air conditioner motor, washing machine motor, compression motor, fan motor, generator motor and pump motor.

Competitive advantages
Variety of application, easy operation.
We directly supply our machine to many countries, like USA, France, Turkey, Iran, India, Brazil, Argentina, Mexico etc.
We could customize machine for our customer.

Information needed for formng machine inquiry
It will be better if customer could send us detailed drawing including below information.
1. Stator lamination drawing
2. Stator stack drawing
3. Stato winding drawing
4. Required productivity
5. Other technical requirement
If possible, it will be better if customer can send us samples.

Economic Type Automatic Stator Winding Final Forming Coil Shaping Machine
Economic Type Automatic Stator Winding Final Forming Coil Shaping MachineEconomic Type Automatic Stator Winding Final Forming Coil Shaping MachineEconomic Type Automatic Stator Winding Final Forming Coil Shaping Machine
With good service, unique philosophy, professional team and reliable quality, we win the worldwide customers' confidence gradually. We directly and indirectly supply our products to more than 50 countries .

Customerized service1. Customized product design and manufacturing2. Customized tranning3.Technical suggestionsAfter-sales service1. Warranty Period: 12 month usually2. Overseas service center available

3. Engineers available to service overseas

Economic Type Automatic Stator Winding Final Forming Coil Shaping Machine
Economic Type Automatic Stator Winding Final Forming Coil Shaping Machine
Established in 2007, NIDE is a company devoted in the field of electric motors manufacturing, providing one-stop service for its customers.

NIDE has three main business divisions.
The first division is to provide different kinds of motor manufacturing machines, it is our Main business, including stand along machine, fully-auto complete line for armature and stator production, and the motor assembly line.
The second division is to supply the full range of motor components such as commutator, ball bearing, carbon brush, insulation paper, shaft, magnet, fan, motor cover, etc.
The third division is to provide technical support and consulting, project support and turn-key service for some motor manufacturing.
